Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
94
C553 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C555 1-124-779-00 ELECT CHIP 10uF 20% 16V
C556 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C559 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C560 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C561 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
C562 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C563 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C564 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C565 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C566 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C568 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C569 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C570 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C571 1-128-065-11 ELECT CHIP 68MF 20% 10V
C573 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C574 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C576 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C577 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
< CONNECTOR >
* CN301 1-564-506-11 PLUG, CONNECTOR 3P
CN501 1-770-706-11 CONNECTOR, FFC/FPC 23P
CN503 1-779-416-11 CONNECTOR,FFC(LIF(NON-ZIF))13P
< TRIMMER >
CT503 1-141-539-11 CAP, ADJ 10PF
< DIODE >
D301 8-719-054-23 DIODE RB706D-40-T146
D501 8-719-422-12 DIODE UDZ-TE-17-3.9B
D502 8-719-018-51 DIODE CL-170R-CD-T (SELF-DIAGNOSIS)
< IC >
IC101 8-759-701-39 IC NJM2100M(TE2)
IC401 8-759-262-00 IC MC14576CFEL (EA,MY,SP,IA)
IC401 8-759-177-02 IC NJM2267M(TE2) (TH)
IC501 8-759-269-92 IC SN74HCU04ANSR
IC502 8-759-587-67 IC M30620MC-A05FP
IC504 8-759-269-92 IC SN74HCU04ANSR
IC505 8-759-535-48 IC CL680T-D1
IC506 8-759-573-23 IC LC372100PM-J48-TLA
IC507 8-759-342-01 IC MSM514260C-60JS
IC509 8-759-535-62 IC PCM1727E-2/T2
< JACK >
J301 1-537-943-11 TERMINAL, S (S VIDEO OUT)
< JUMPER RESISTOR >
JW101 1-216-295-91 SHORT 0
JW201 1-216-295-91 SHORT 0
JW401 1-216-295-91 SHORT 0
JW402 1-216-295-91 SHORT 0
JW403 1-216-295-91 SHORT 0
JW404 1-216-295-91 SHORT 0
JW405 1-216-295-91 SHORT 0
JW413 1-216-295-91 SHORT 0
JW421 1-216-295-91 SHORT 0
JW422 1-216-295-91 SHORT 0
JW502 1-216-295-91 SHORT 0
JW503 1-216-295-91 SHORT 0
JW504 1-216-295-91 SHORT 0
JW505 1-216-295-91 SHORT 0
< COIL >
L301 1-410-372-21 INDUCTOR CHIP 1.8uH
L302 1-410-372-21 INDUCTOR CHIP 1.8uH
L501 1-216-296-91 SHORT 0
L502 1-216-296-91 SHORT 0
L503 1-216-296-91 SHORT 0
L504 1-410-375-11 INDUCTOR CHIP 3.3uH
L505 1-216-296-91 SHORT 0
L506 1-216-296-91 SHORT 0
L507 1-216-296-91 SHORT 0
L508 1-216-296-91 SHORT 0
L509 1-216-296-91 SHORT 0
L510 1-216-296-91 SHORT 0
< TRANSISTOR >
Q301 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q302 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q303 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q304 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q306 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q307 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q308 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q310 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q453 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q454 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q502 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q531 8-729-140-75 TRANSISTOR 2SD999-T1-CLCK
< RESISTOR >
R101 1-216-073-00 METAL CHIP 10K 5% 1/10W
R102 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R103 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R105 1-216-295-91 SHORT 0
R201 1-216-073-00 METAL CHIP 10K 5% 1/10W
R202 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R203 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R205 1-216-295-91 SHORT 0
R301 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R302 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R305 1-216-049-91 RES,CHIP 1K 5% 1/10W
(EA,MY,SP,IA)
R305 1-216-041-00 METAL CHIP 470 5% 1/10W
(TH)
R306 1-216-073-00 METAL CHIP 10K 5% 1/10W
R307 1-216-049-91 RES,CHIP 1K 5% 1/10W
R308 1-216-049-91 RES,CHIP 1K 5% 1/10W
R309 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R312 1-216-073-00 METAL CHIP 10K 5% 1/10W
R313 1-216-049-91 RES,CHIP 1K 5% 1/10W
(EA,MY,SP,IA)
R313 1-216-033-00 METAL CHIP 220 5% 1/10W
(TH)
R314 1-216-049-91 RES,CHIP 1K 5% 1/10W
(EA,MY,SP,IA)
VIDEO
