Base unit
6
5
Four screws (+PTPWH 2.6
)
3
Screw (+BVTT 2.6
×
8)
4
BD board
8
Two insulators
7
Two insulators
1
Flat type wire (CN101)
2
Flat type wire (CN102)
8
Pull-out the disc tray.
5
Three
screws (+BVTP 2.6
×
8)
9
Screw (+PTPWH 2.6
×
8)
q;
Tray
1
Screw (+BVTP 2.6
×
8)
qa
Screw (+BVTP 2.6
×
8)
4
Flat type wire (CN721)
7
Motor board
qs
Address sensor board
2
Driver board
3
Connector (CN701)
6
Remove the two solderings of motor.
3-9. BASE UNIT
3-10. DRIVER BOARD, MOTOR BOARD AND ADDRESS SENSOR BOARD
