SECTION 1
SERVICE NOTE
MODEL IDENTIFICATION
— BACK PANEL —
MODEL
E, EA, HK, MY, SP, TW, JE models
TH model
IA model
PARTS No.
4-224-547-3s
4-224-547-5s
4-226-245-4s
PARTS No.
• Abbreviation
EA :Saudi Arabia model
MY :Malaysia model
SP :Singapore model
TH :Thai model
TW :Taiwan model
IA :Indonesia model
HK :Hong Kong model
JE :Tourist model
Screw hole
Attach the panel board with
fourteen screws (
+BVTP 2.6
×
8
)
after the board is removed once.
Do not tighten the screws excessively.
1
Cut the fourteen melted-connection points with a cutting plier.
Note for installing the panel board
2
Panel board
Hot melt
To Next Page
