NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
60
SECTION 9
ELECTRICAL PARTS LIST
• Abbreviation
EA : Saudi Arabia model
MY : Malaysia model
SP : Singapore model
TH : Thai model
TW : Taiwan model
IA : Indonesia model
HK : Hong Kong model
JE : Tourist model
ADDRESS SENSOR
1-675-911-11 ADDRESS SENSOR BOARD
**********************
< IC >
IC711 8-749-014-38 PHOTO INTERRUPTER SG-264
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W F
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY)(UP/DOWN)
**************************************************************
A-4428-064-A AMP BOARD, COMPLETE (IA)
*******************
A-4428-064-A AMP BOARD, COMPLETE
(E,EA,HK,MY,SP,TW,JE)
*******************
A-4428-590-A AMP BOARD, COMPLETE (TH)
*******************
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20.00% 50V
C502 1-162-290-31 CERAMIC 470PF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-128-551-11 ELECT 22uF 20.00% 25V
C507 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C508 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C509 1-128-560-11 ELECT 22uF 20.00% 100V
C511 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C541 1-130-777-00 MYLAR 0.1uF 10.00% 100V
C542 1-127-812-11 ELECT 3300uF 20% 63V
C543 1-164-159-11 CERAMIC 0.1uF 50V
C544 1-126-942-61 ELECT 1000uF 20.00% 25V
C545 1-128-549-11 ELECT 3300uF 20.00% 35V
C551 1-126-964-11 ELECT 10uF 20.00% 50V
C552 1-162-290-31 CERAMIC 470PF 10% 50V
C553 1-162-282-31 CERAMIC 100PF 10% 50V
C554 1-128-551-11 ELECT 22uF 20.00% 25V
C557 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C558 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C559 1-128-560-11 ELECT 22uF 20.00% 100V
C591 1-130-777-00 MYLAR 0.1uF 10.00% 100V
C592 1-127-812-11 ELECT 3300uF 20% 63V
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN504 1-785-314-11 PIN, CONNECTOR (STRAIGHT) 2P
< DIODE >
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-911-19 DIODE 1SS133T-72
D541 8-719-302-38 DIODE RBV-602-01
D542 8-719-024-99 DIODE 11ES2-NTA2B
D543 8-719-024-99 DIODE 11ES2-NTA2B
D551 8-719-911-19 DIODE 1SS133T-72
< EARTH >
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-016-95 IC STK402-100S
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q582 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q583 8-729-900-36 TRANSISTOR BA1F4M-TP
Q584 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-414-11 CARBON 560 5% 1/4W F
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W F
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0R508 1-217-156-00 METAL 0.22 20% 5W
R509 1-260-076-11 CARBON 10 5% 1/2W
0R510 1-217-156-00 METAL 0.22 20% 5W
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
AMP
