Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
62
DRIVER HEAD (A) HEAD (B) LEAF SW
R147 1-216-041-00 METAL CHIP 470 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-003-11 RES-CHIP 12 5% 1/10W
R150 1-216-073-00 METAL CHIP 10K 5% 1/10W
R154 1-216-025-91 RES-CHIP 100 5% 1/10W
R155 1-216-025-91 RES-CHIP 100 5% 1/10W
R156 1-216-025-91 RES-CHIP 100 5% 1/10W
R157 1-216-025-91 RES-CHIP 100 5% 1/10W
R158 1-216-073-00 METAL CHIP 10K 5% 1/10W
R159 1-216-089-91 RES-CHIP 47K 5% 1/10W
R161 1-216-295-91 SHORT 0
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-025-91 RES-CHIP 100 5% 1/10W
R172 1-216-025-91 RES-CHIP 100 5% 1/10W
R173 1-216-025-91 RES-CHIP 100 5% 1/10W
R175 1-216-025-91 RES-CHIP 100 5% 1/10W
R180 1-216-097-91 RES-CHIP 100K 5% 1/10W
R181 1-216-100-00 RES-CHIP 130K 5% 1/10W
R182 1-216-081-00 METAL CHIP 22K 5% 1/10W
R183 1-216-081-00 METAL CHIP 22K 5% 1/10W
R184 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R185 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R186 1-216-081-00 METAL CHIP 22K 5% 1/10W
R187 1-216-081-00 METAL CHIP 22K 5% 1/10W
R188 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R189 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R190 1-216-081-00 METAL CHIP 22K 5% 1/10W
R191 1-216-081-00 METAL CHIP 22K 5% 1/10W
R192 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R193 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R194 1-216-295-91 SHORT 0
R203 1-216-025-91 RES-CHIP 100 5% 1/10W
R204 1-216-025-91 RES-CHIP 100 5% 1/10W
R205 1-216-025-91 RES-CHIP 100 5% 1/10W
R206 1-216-295-91 SHORT 0
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT IN)
**************************************************************
1-675-912-11 DRIVER BOARD
***********
< CAPACITOR >
C702 1-126-964-51 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN701 1-785-336-11 PIN, CONNECTOR(LIGHT ANGLE)10P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< DIODE >
D701 8-719-109-66 DIODE MTZJ-T-77-3.3B
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
1-676-220-11 HEAD(A) BOARD
**************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
**************************************************************
1-676-221-11 HEAD(B) BOARD
*************
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
**************************************************************
A-2007-846-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20.00% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1004 1-771-205-11 SWITCH, LEAF (A 120/70)
S1005 1-771-205-11 SWITCH, LEAF (REC A)
