Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
69
MAIN MOTOR PANEL
RV352 1-241-762-11 RES, ADJ, CARBON 2.2K
RV353 1-241-762-11 RES, ADJ, CARBON 2.2K
RV354 1-241-768-11 RES, ADJ, CARBON 220K
RV611 1-241-765-11 RES, ADJ, CARBON 22K
< RELAY >
RY801 1-755-373-11 RELAY
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
T601 1-435-195-11 TRANSFORMER, DISCRIMINATOR
< TERMINAL >
TM601 1-694-555-11 TERMINAL BOARD (4P) (FM/AM)
TM801 1-694-635-11 TERMINAL BOARD (4P) (SPEAKER)
< VIBRATOR >
X401 1-567-098-41 VIBRATOR, CRYSTAL 32.768KHz
X402 1-781-107-21 VIBRATOR, SERAMIC 16MHz
X651 1-760-549-31 VIBRATOR, CRYSTAL 4.5MHz
**************************************************************
1-675-910-11 MOTOR BOARD
*************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE)
**************************************************************
A-4428-035-A PANEL BOARD, COMPLETE
(E,EA,HK,MY,SP,TW,JE)
*********************
A-4428-607-A PANEL BOARD, COMPLETE (TH)
*********************
A-4428-539-A PANEL BOARD, COMPLETE (IA)
*********************
4-224-584-11 HOLDER(FL)
< CAPACITOR >
C601 1-124-589-11 ELECT 47uF 20% 16V
C602 1-126-163-11 ELECT 4.7uF 20% 50V
C603 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C604 1-162-294-31 CERAMIC 0.001uF 10% 50V
C605 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C607 1-124-589-11 ELECT 47uF 20% 16V
C608 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C609 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C610 1-126-157-11 ELECT 10uF 20% 16V
C611 1-126-157-11 ELECT 10uF 20% 16V
C612 1-162-303-11 CERAMIC 0.0033uF 30.00% 16V
C613 1-126-157-11 ELECT 10uF 20% 16V
C614 1-126-157-11 ELECT 10uF 20% 16V
C615 1-126-163-11 ELECT 4.7uF 20% 50V
C616 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C617 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C618 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C620 1-126-157-11 ELECT 10uF 20% 16V
C622 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C623 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C624 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C631 1-162-294-31 CERAMIC 0.001uF 10% 50V
C632 1-162-294-31 CERAMIC 0.001uF 10% 50V
C633 1-164-159-11 CERAMIC 0.1uF 50V
C652 1-126-966-11 ELECT 33uF 20.00% 50V
C653 1-126-966-11 ELECT 33uF 20.00% 50V
C655 1-162-282-31 CERAMIC 100PF 10% 50V
C656 1-162-282-31 CERAMIC 100PF 10% 50V
C657 1-162-282-31 CERAMIC 100PF 10% 50V
C658 1-162-282-31 CERAMIC 100PF 10% 50V
C659 1-162-282-31 CERAMIC 100PF 10% 50V
C660 1-162-282-31 CERAMIC 100PF 10% 50V
C661 1-162-282-31 CERAMIC 100PF 10% 50V
C662 1-162-282-31 CERAMIC 100PF 10% 50V
C663 1-162-282-31 CERAMIC 100PF 10% 50V
C664 1-162-282-31 CERAMIC 100PF 10% 50V
C665 1-162-282-31 CERAMIC 100PF 10% 50V
C666 1-162-282-31 CERAMIC 100PF 10% 50V
C667 1-162-282-31 CERAMIC 100PF 10% 50V
C668 1-162-282-31 CERAMIC 100PF 10% 50V
C669 1-162-282-31 CERAMIC 100PF 10% 50V
C670 1-162-282-31 CERAMIC 100PF 10% 50V
C671 1-162-282-31 CERAMIC 100PF 10% 50V
C697 1-162-282-31 CERAMIC 100PF 10% 50V
C719 1-104-665-11 ELECT 100uF 20.00% 10V
C720 1-104-665-11 ELECT 100uF 20.00% 10V
C721 1-162-294-31 CERAMIC 0.001uF 10% 50V
C722 1-162-305-11 CERAMIC 0.0068uF 30.00% 16V
C723 1-126-160-11 ELECT 1uF 20% 50V
C724 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C725 1-124-465-00 ELECT 0.47uF 20% 50V
C726 1-124-465-00 ELECT 0.47uF 20% 50V
C727 1-136-167-00 MYLAR 0.15uF 5.00% 50V
C728 1-162-294-31 CERAMIC 0.001uF 10% 50V
C729 1-126-160-11 ELECT 1uF 20% 50V
C730 1-161-494-00 CERAMIC 0.022uF 25V
C731 1-162-305-11 CERAMIC 0.0068uF 30.00% 16V
C732 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C733 1-124-589-11 ELECT 47uF 20% 16V
C734 1-124-589-11 ELECT 47uF 20% 16V
C735 1-124-257-00 ELECT 2.2uF 20% 50V
C736 1-124-261-00 ELECT 10uF 20% 50V
C737 1-124-261-00 ELECT 10uF 20% 50V
C738 1-124-257-00 ELECT 2.2uF 20% 50V
C739 1-162-215-31 CERAMIC 47PF 5% 50V
C740 1-162-282-31 CERAMIC 100PF 10% 50V
C741 1-124-463-00 ELECT 0.1uF 20% 50V
C742 1-162-215-31 CERAMIC 47PF 5% 50V
C743 1-162-290-31 CERAMIC 470PF 10% 50V
C744 1-162-294-31 CERAMIC 0.001uF 10% 50V
