Sony HCD-VX77 - Page 79

79
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R731 1-247-881-00 CARBON 120K 5% 1/4W
R732 1-249-417-11 CARBON 1K 5% 1/4W F
R733 1-249-429-11 CARBON 10K 5% 1/4W
R734 1-247-807-31 CARBON 100 5% 1/4W
R735 1-247-885-00 CARBON 180K 5% 1/4W
R736 1-249-429-11 CARBON 10K 5% 1/4W
R737 1-249-437-11 CARBON 47K 5% 1/4W
R738 1-249-417-11 CARBON 1K 5% 1/4W F
R739 1-249-441-11 CARBON 100K 5% 1/4W
R740 1-249-417-11 CARBON 1K 5% 1/4W F
R741 1-249-429-11 CARBON 10K 5% 1/4W
R742 1-249-417-11 CARBON 1K 5% 1/4W F
R744 1-249-441-11 CARBON 100K 5% 1/4W
R745 1-247-807-31 CARBON 100 5% 1/4W
R746 1-249-417-11 CARBON 1K 5% 1/4W F
R747 1-260-093-11 CARBON 330 5% 1/2W
< VARIABLE RESISTOR >
RV721 1-225-739-11 RES, VAR CARBON 50K
RV722 1-225-739-11 RES, VAR CARBON 50K
< SWITCH >
S601 1-418-725-11 ENCODER, ROTARY (12 TYPE) (VOLUME)
S611 1-762-875-21 SWITCH, KEYBOARD (v)
S612 1-762-875-21 SWITCH, KEYBOARD (V)
S613 1-762-875-21 SWITCH, KEYBOARD (V-GROOVE)
S614 1-762-875-21 SWITCH, KEYBOARD (LOOP)
S615 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S616 1-762-875-21 SWITCH, KEYBOARD (REC/PAUSE)
S617 1-762-875-21 SWITCH, KEYBOARD (ENTER/NEXT)
S618 1-762-875-21 SWITCH, KEYBOARD (M)
S619 1-762-875-21 SWITCH, KEYBOARD (AMS +)
S620 1-762-875-21 SWITCH, KEYBOARD (PAUSE)
S621 1-762-875-21 SWITCH, KEYBOARD (- AMS)
S622 1-762-875-21 SWITCH, KEYBOARD (PICTURE EFFECT)
S623 1-762-875-21 SWITCH, KEYBOARD (b)
S624 1-762-875-21 SWITCH, KEYBOARD (B)
S625 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S626 1-762-875-21 SWITCH, KEYBOARD (STOP)
S627 1-762-875-21 SWITCH, KEYBOARD (CD)
S628 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S629 1-762-875-21 SWITCH, KEYBOARD (PLAY)
S630 1-762-875-21 SWITCH, KEYBOARD (MD (VIDEO))
S631 1-762-875-21 SWITCH, KEYBOARD (m)
S632 1-762-875-21 SWITCH, KEYBOARD (CHINEMA SPACE)
S633 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
S634 1-762-875-21 SWITCH, KEYBOARD (REPEAT)
S635 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S636 1-762-875-21 SWITCH, KEYBOARD (EDIT)
S637 1-762-875-21 SWITCH, KEYBOARD (?/1)
S638 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S639 1-762-875-21 SWITCH, KEYBOARD (EQ EDIT)
S640 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S641 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
< VIBRATOR >
X601 1-579-352-11 VIBRATOR, CERAMIC 12.5MHz
**************************************************************
A-4428-344-A POWER AMP BOARD, COMPLETE
(VX77:MY,SP,EA,HK,IA,E)
**************************************
A-4473-170-A POWER AMP BOARD, COMPLETE (VX77:TH)
*********************************
A-4473-342-A POWER AMP BOARD, COMPLETE (VX77J)
*******************************
7-685-646-79 SCREW +BVTP3X8 TYPE2 N-S
< CAPACITOR >
C501 1-126-963-11 ELECT 4.7uF 20.00% 50V
C502 1-162-290-31 CERAMIC 470PF 10% 50V
C503 1-162-286-21 CERAMIC 220PF 10.00% 50V
C504 1-104-665-11 ELECT 100uF 20.00% 10V
C507 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C508 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C509 1-128-560-11 ELECT 22uF 20.00% 100V
C510 1-128-578-11 ELECT 1uF 20.00% 100V
C511 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C541 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C542 1-127-752-11 ELECT 3300uF 20% 63V
C544 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C545 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C546 1-127-755-11 ELECT 3300uF 20% 100V
C551 1-126-963-11 ELECT 4.7uF 20.00% 50V
C552 1-162-290-31 CERAMIC 470PF 10% 50V
C553 1-162-286-21 CERAMIC 220PF 10.00% 50V
C554 1-104-665-11 ELECT 100uF 20.00% 10V
C557 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C558 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C559 1-128-560-11 ELECT 22uF 20.00% 100V
C581 1-126-967-11 ELECT 47uF 20.00% 50V
C591 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C592 1-127-752-11 ELECT 3300uF 20% 63V
C596 1-127-755-11 ELECT 3300uF 20% 100V
C942 1-126-964-11 ELECT 10uF 20.00% 50V
C943 1-126-968-11 ELECT 100uF 20.00% 50V
C980 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN502 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D503 8-719-922-03 DIODE MTZJ-T-77-18C
D504 8-719-922-03 DIODE MTZJ-T-77-18C
D541 8-719-302-38 DIODE RBV-602-01
D543 8-719-302-37 DIODE RBV-602
D551 8-719-991-33 DIODE 1SS133T-77
D581 8-719-991-33 DIODE 1SS133T-77
D941 8-719-110-90 DIODE MTZJ-T-77-39D
D979 8-719-110-31 DIODE MTZJ-T-77-12B
< TERMINAL >
* EP501 1-537-738-21 TERMINAL, EARTH
PANEL
POWER AMP
