Sony HCD-VX77 - Page 80

80
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< IC >
IC501 8-749-017-06 IC STK412-150
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q505 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q506 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q941 8-729-048-52 TRANSISTOR 2SA1932 (TP)
Q942 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-412-11 CARBON 390 5% 1/4W
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W F
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
R508 1-220-891-11 METAL 0.1 10% 5W
R509 1-260-076-11 CARBON 10 5% 1/2W
R510 1-220-891-11 METAL 0.1 10% 5W
0 R511 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R512 1-202-972-61 FUSIBLE 1 5% 1/4W
R513 1-249-435-11 CARBON 33K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W F
R515 1-247-863-91 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W F
R518 1-249-435-11 CARBON 33K 5% 1/4W
R519 1-249-439-11 CARBON 68K 5% 1/4W
R520 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-441-11 CARBON 100K 5% 1/4W
R524 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R541 1-249-441-11 CARBON 100K 5% 1/4W
R542 1-249-441-11 CARBON 100K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-412-11 CARBON 390 5% 1/4W
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W F
R556 1-249-431-11 CARBON 15K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
R558 1-220-891-11 METAL 0.1 10% 5W
R559 1-260-076-11 CARBON 10 5% 1/2W
R560 1-220-891-11 METAL 0.1 10% 5W
0 R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-249-441-11 CARBON 100K 5% 1/4W
R592 1-249-441-11 CARBON 100K 5% 1/4W
R941 1-216-478-11 METAL OXIDE 390 5% 3W
R942 1-249-429-11 CARBON 10K 5% 1/4W
R943 1-249-417-11 CARBON 1K 5% 1/4W F
R944 1-247-791-91 CARBON 22 5% 1/4W
R980 1-249-429-11 CARBON 10K 5% 1/4W
< THERMISTOR >
TH501 1-807-796-11 THERMISTOR
**************************************************************
1-675-911-11 SENSOR BOARD
***********
< CAPACITOR >
C712 1-164-159-21 CERAMIC 0.1uF 50V
< IC >
IC711 8-749-016-76 IC RPI-321
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-247-815-91 CARBON 220 5% 1/4W
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (UP/DOWN)
**************************************************************
A-4428-346-A TRANS BOARD, COMPLETE
(VX77:MY,SP,EA,HK,IA,E)
*******************************************
A-4473-166-A TRANS BOARD, COMPLETE (VX77:TH)
*****************************
A-4473-345-A TRANS BOARD, COMPLETE (VX77J)
***************************
1-533-293-31 FUSE HOLDER
< CONNECTOR >
CN975 1-564-321-00 PIN, CONNECTOR 2P
* CN977 1-564-528-11 PLUG, CONNECTOR 13P
< FUSE >
0 F971 1-532-506-31 FUSE T6.3AL 250V (EXCEPT TH)
0 F974 1-532-506-31 FUSE T6.3AL 250V
0 F975 1-532-506-31 FUSE T6.3AL 250V
0 F976 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) T8AL 250V
0 F977 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) T8AL 250V
< RESISTOR >
0 R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W
< SWITCH >
0 S951 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
(EXCEPT TH)
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
POWER AMP
SENSOR
TRANS
