Sony HCD-VX77 - Page 81

81
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
TRANS
< TRANSFORMER >
0 T971 1-435-262-11 TRANSFORMER, POWER (VX77J)
0 T971 1-435-325-11 POWER TRANSFORMER (VX77)
**************************************************************
A-4724-973-A VIDEO BOARD, COMPLETE
********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C304 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C305 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C306 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C307 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C308 1-163-263-11 CERAMIC CHIP 330PF 5.00% 50V
C309 1-163-263-11 CERAMIC CHIP 330PF 5.00% 50V
C310 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C311 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C312 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C313 1-163-259-91 CERAMIC CHIP 220PF 5.00% 50V
C314 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C315 1-163-255-11 CERAMIC CHIP 150PF 5.00% 50V
C316 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C317 1-126-193-11 ELECT 1uF 20% 50V
C318 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C319 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C320 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C321 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C322 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C323 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C324 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C325 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C402 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C504 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C505 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C506 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C507 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C508 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C509 1-163-275-11 CERAMIC CHIP 0.001uF 5.00% 50V
C510 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C531 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C532 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C535 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C536 1-126-193-11 ELECT 1uF 20% 50V
C537 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C539 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C540 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C541 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C542 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C543 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C544 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C545 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C546 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C547 1-126-193-11 ELECT 1uF 20% 50V
C548 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C549 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C550 1-163-275-11 CERAMIC CHIP 0.001uF 5.00% 50V
C551 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C552 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C553 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C555 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C556 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C559 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C561 1-163-233-11 CERAMIC CHIP 18PF 5.00% 50V
C563 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C564 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C565 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C566 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C568 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C569 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C570 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C571 1-128-065-11 ELECT CHIP 68uF 20.00% 10V
C573 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C574 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C576 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C577 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
< CONNECTOR >
CN501 1-779-343-21 CONNECTOR, FFC/FPC 23P
CN502 1-779-416-11 CONNECTOR,FFC (LIF (NON-ZIF))13P
CN503 1-774-766-21 CONNECTOR, FFC/FPC 11P
< TRIMMER >
CT503 1-141-539-11 CAP, ADJ 10PF
< DIODE >
D501 8-719-422-12 DIODE UDZ-TE-17-3.9B
< IC >
IC101 8-759-701-40 IC NJM2100M (TE2)
IC301 8-759-530-30 IC TC74VHCU04FT (EL)
IC302 8-759-662-94 IC NJM2255M (TE2)
IC303 8-759-711-47 IC NJM2209M (TE2)
IC304 8-759-662-95 IC BA7665FS-E2
IC501 8-759-530-30 IC TC74VHCU04FT (EL)
IC502 8-759-663-01 IC M30624MCA-A34FP
IC504 8-759-530-30 IC TC74VHCU04FT (EL)
IC505 8-759-535-48 IC CL680T-D1
IC506 8-759-677-67 IC LC372100PM-K98-TLA
IC507 8-759-342-01 IC MSM514260C-60JS
IC509 8-759-535-62 IC PCM1727E-2/T2
< JACK >
J301 1-537-943-11 TERMINAL, S (S VIDEO OUT)
J302 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< JUMPER RESISTOR >
JW101 1-216-295-91 SHORT 0
JW201 1-216-295-91 SHORT 0
JW301 1-216-295-91 SHORT 0
JW302 1-216-025-91 RES-CHIP 100 5% 1/10W
JW304 1-216-295-91 SHORT 0
VIDEO
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
