82
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
JW413 1-216-295-91 SHORT 0
JW504 1-216-295-91 SHORT 0
JW505 1-216-295-91 SHORT 0
JW513 1-216-295-91 SHORT 0
< COIL >
L301 1-410-372-21 INDUCTOR CHIP 1.8uH
L302 1-410-372-21 INDUCTOR CHIP 1.8uH
L303 1-410-658-31 INDUCTOR CHIP 220uH
L501 1-216-296-91 SHORT 0
L502 1-216-296-91 SHORT 0
L504 1-410-375-11 INDUCTOR CHIP 3.3uH
L505 1-216-296-91 SHORT 0
L506 1-216-296-91 SHORT 0
L507 1-216-296-91 SHORT 0
L508 1-216-296-91 SHORT 0
L509 1-216-296-91 SHORT 0
L510 1-216-296-91 SHORT 0
L511 1-469-145-21 FERRITE 0uH
L512 1-469-145-21 FERRITE 0uH
L513 1-469-145-21 FERRITE 0uH
< TRANSISTOR >
Q501 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q502 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q531 8-729-140-75 TRANSISTOR 2SD999-T1-CLCK
< RESISTOR >
R101 1-216-073-00 METAL CHIP 10K 5% 1/10W
R102 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R103 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R201 1-216-073-00 METAL CHIP 10K 5% 1/10W
R202 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R203 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R302 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R303 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R306 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R308 1-216-073-00 METAL CHIP 10K 5% 1/10W
R309 1-216-073-00 METAL CHIP 10K 5% 1/10W
R310 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R311 1-216-029-00 METAL CHIP 150 5% 1/10W
R312 1-216-073-00 METAL CHIP 10K 5% 1/10W
R313 1-216-073-00 METAL CHIP 10K 5% 1/10W
R314 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R315 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R316 1-216-022-00 METAL CHIP 75 5% 1/10W
R317 1-216-022-00 METAL CHIP 75 5% 1/10W
R318 1-216-295-91 SHORT 0
R319 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R320 1-216-295-91 SHORT 0
R403 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R404 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R501 1-216-025-91 RES-CHIP 100 5% 1/10W
R502 1-216-025-91 RES-CHIP 100 5% 1/10W
R503 1-216-025-91 RES-CHIP 100 5% 1/10W
R504 1-216-025-91 RES-CHIP 100 5% 1/10W
R505 1-216-025-91 RES-CHIP 100 5% 1/10W
R506 1-216-025-91 RES-CHIP 100 5% 1/10W
R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-073-00 METAL CHIP 10K 5% 1/10W
R516 1-216-073-00 METAL CHIP 10K 5% 1/10W
R517 1-216-073-00 METAL CHIP 10K 5% 1/10W
R518 1-216-073-00 METAL CHIP 10K 5% 1/10W
R519 1-216-025-91 RES-CHIP 100 5% 1/10W
R520 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R521 1-216-073-00 METAL CHIP 10K 5% 1/10W
R523 1-216-013-00 METAL CHIP 33 5% 1/10W
R530 1-216-025-91 RES-CHIP 100 5% 1/10W
R531 1-216-025-91 RES-CHIP 100 5% 1/10W
R532 1-216-295-91 SHORT 0
R533 1-216-295-91 SHORT 0
R534 1-216-073-00 METAL CHIP 10K 5% 1/10W
R535 1-216-073-00 METAL CHIP 10K 5% 1/10W
R536 1-216-033-00 METAL CHIP 220 5% 1/10W
R537 1-216-025-91 RES-CHIP 100 5% 1/10W
R538 1-216-073-00 METAL CHIP 10K 5% 1/10W
R539 1-216-295-91 SHORT 0
R540 1-216-295-91 SHORT 0
R542 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R543 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R544 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R545 1-216-025-91 RES-CHIP 100 5% 1/10W
R546 1-216-049-91 RES-CHIP 1K 5% 1/10W
R548 1-216-049-91 RES-CHIP 1K 5% 1/10W
R549 1-216-025-91 RES-CHIP 100 5% 1/10W
R550 1-216-025-91 RES-CHIP 100 5% 1/10W
R551 1-216-025-91 RES-CHIP 100 5% 1/10W
R552 1-216-025-91 RES-CHIP 100 5% 1/10W
R555 1-216-121-91 RES-CHIP 1M 5% 1/10W
R556 1-216-025-91 RES-CHIP 100 5% 1/10W
R557 1-216-025-91 RES-CHIP 100 5% 1/10W
R560 1-216-653-11 METAL CHIP 1.2K 0.5% 1/10W
R561 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R562 1-216-073-00 METAL CHIP 10K 5% 1/10W
R563 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-081-00 METAL CHIP 22K 5% 1/10W
R578 1-216-081-00 METAL CHIP 22K 5% 1/10W
R579 1-216-073-00 METAL CHIP 10K 5% 1/10W
R580 1-216-073-00 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X501 1-767-510-11 VIBRATOR, CERAMIC 10MHz
X503 1-767-519-11 VIBRATOR, CRYSTAL 27MHz
**************************************************************
VIDEO
