Sony HCD-VX77 - Page 83

83
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX77/VX77J
MISCELLANEOUS
*************
11 1-792-246-11 WIRE (FLAT TYPE) (23 CORE)
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
104 1-769-987-11 WIRE (FLAT TYPE) (13 CORE)
0 108 1-575-653-11 CORD, POWER (VX77:E,IA,VX77J)
0 108 1-777-071-51 CORD, POWER (VX77:MY,SP,EA,HK)
0 108 1-791-901-11 CORD, POWER (VX77:TH)
0 109 1-569-007-11 ADAPTOR, CONVERSION 2P (VX77:E,IA,VX77J)
0 109 1-569-008-21 ADAPTOR, CONVERSION (VX77:MY,SP,EA)
0 109 1-569-008-31 ADAPTOR, CONVERSION (VX77:MY,SP,EA)
0 109 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (VX77:HK)
259 1-791-983-11 WIRE (FLAT TYPE) (8 CORE)
266 1-471-035-11 MAGNET ASSY
0301 8-820-116-01 OPTICAL PICK-UP KSM-213DAP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP101 A-2004-778-A BASE (A) ASSY, HEAD
HRPE101 A-2004-779-A BASE (B) ASSY, HEAD
M1 X-3378-241-1 MOTOR ASSY (INCLUDING PULLEY)
M721 A-4672-826-A MOTOR ASSY (INCLUDING PULLEY)
M961 1-763-072-11 FAN, DC
FL601 1-517-928-11 INDICATOR TUBE, FLUORESCENT
**************************************************************
**************
HARDWARE LIST
**************
#1 7-628-254-05 SCREW +PS 2.6X5
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#5 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#6 7-685-881-09 SCREW +BVTT 4X8 (S)
#7 7-685-781-09 SCREW +PTT 2X4 (S)
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Ver 1.1 2001.08
