qs Cut the eleven melted-connection points with a cutting plier.
Note: When attching the panel board,
refer to "Service Note" on page 4.
qf Panel board
qa CD Switch boar
d
1 Knob (Volume)
8
5
FR knob
4 Bracket (FR)
qd Five claws
0 Three claws
9 Three screws
(+BVTP 2.6
× 8)
3 Two bosses & four pins
6 Spring
2 Two screws
(+BVTP 2.6
× 8)
7 Knob(MIC)
8 Two screws
(+BVTT 4
× 8)
2 Six screws
(+BVTP 3
× 10
)
1 Two screws
(+BVTP 3
× 10)
4 Panel, back
7 Two screws (+BVTT 4 × 8)
0 Trans board
9 Trans
5 Connector (CN975)
6 Connector (CN977)
3 Connector (CN891)
3-5. PANEL BOARD
3-6. TRANS BOARD
