Sony HCD-VX880AV - Page 81

81
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R451 1-216-025-91 RES,CHIP 100 5% 1/10W
R452 1-216-085-00 METAL CHIP 33K 5% 1/10W
R461 1-260-089-11 CARBON 150 5% 1/2W
R462 1-260-089-11 CARBON 150 5% 1/2W
R463 1-260-313-51 CARBON 56 5% 1/2W
R464 1-216-049-91 RES,CHIP 1K 5% 1/10W
R468 1-260-089-11 CARBON 150 5% 1/2W
R469 1-260-089-11 CARBON 150 5% 1/2W
R502 1-216-041-00 METAL CHIP 470 5% 1/10W
R503 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R504 1-216-025-91 RES,CHIP 100 5% 1/10W
R505 1-216-089-91 RES,CHIP 47K 5% 1/10W
R506 1-216-089-91 RES,CHIP 47K 5% 1/10W
R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-033-00 METAL CHIP 220 5% 1/10W
R509 1-216-097-91 RES,CHIP 100K 5% 1/10W
R510 1-216-295-91 SHORT 0
R511 1-216-109-00 METAL CHIP 330K 5% 1/10W
R513 1-216-295-91 SHORT 0
R517 1-216-073-00 METAL CHIP 10K 5% 1/10W
R518 1-216-025-91 RES,CHIP 100 5% 1/10W
R522 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R526 1-216-025-91 RES,CHIP 100 5% 1/10W
R527 1-216-025-91 RES,CHIP 100 5% 1/10W
R528 1-216-073-00 METAL CHIP 10K 5% 1/10W
R529 1-216-025-91 RES,CHIP 100 5% 1/10W
R530 1-216-025-91 RES,CHIP 100 5% 1/10W
R536 1-216-025-91 RES,CHIP 100 5% 1/10W
R538 1-216-073-00 METAL CHIP 10K 5% 1/10W
R539 1-216-025-91 RES,CHIP 100 5% 1/10W
R542 1-216-025-91 RES,CHIP 100 5% 1/10W
R543 1-216-025-91 RES,CHIP 100 5% 1/10W
R549 1-216-049-91 RES,CHIP 1K 5% 1/10W
R550 1-216-025-91 RES,CHIP 100 5% 1/10W
R551 1-216-025-91 RES,CHIP 100 5% 1/10W
R552 1-216-025-91 RES,CHIP 100 5% 1/10W
R553 1-216-025-91 RES,CHIP 100 5% 1/10W
R554 1-216-025-91 RES,CHIP 100 5% 1/10W
R555 1-216-025-91 RES,CHIP 100 5% 1/10W
R559 1-216-025-91 RES,CHIP 100 5% 1/10W
R560 1-216-025-91 RES,CHIP 100 5% 1/10W
R561 1-216-025-91 RES,CHIP 100 5% 1/10W
R563 1-216-025-91 RES,CHIP 100 5% 1/10W
R565 1-216-025-91 RES,CHIP 100 5% 1/10W
R566 1-216-025-91 RES,CHIP 100 5% 1/10W
R567 1-216-025-91 RES,CHIP 100 5% 1/10W
R568 1-216-025-91 RES,CHIP 100 5% 1/10W
R569 1-216-025-91 RES,CHIP 100 5% 1/10W
R570 1-216-025-91 RES,CHIP 100 5% 1/10W
R571 1-216-025-91 RES,CHIP 100 5% 1/10W
R572 1-216-073-00 METAL CHIP 10K 5% 1/10W
R573 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R574 1-216-073-00 METAL CHIP 10K 5% 1/10W
R575 1-216-073-00 METAL CHIP 10K 5% 1/10W
R576 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-073-00 METAL CHIP 10K 5% 1/10W
R578 1-216-073-00 METAL CHIP 10K 5% 1/10W
R586 1-216-025-91 RES,CHIP 100 5% 1/10W
R587 1-216-025-91 RES,CHIP 100 5% 1/10W
R588 1-216-025-91 RES,CHIP 100 5% 1/10W
R589 1-216-025-91 RES,CHIP 100 5% 1/10W
R590 1-216-025-91 RES,CHIP 100 5% 1/10W
R591 1-216-025-91 RES,CHIP 100 5% 1/10W
R594 1-216-295-91 SHORT 0
R595 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R596 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R597 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R598 1-216-045-00 METAL CHIP 680 5% 1/10W
R901 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R902 1-216-045-00 METAL CHIP 680 5% 1/10W
R903 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R904 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R905 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R906 1-216-043-91 RES,CHIP 560 5% 1/10W
R907 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R908 1-216-073-00 METAL CHIP 10K 5% 1/10W
R909 1-216-075-00 METAL CHIP 12K 5% 1/10W
R910 1-216-073-00 METAL CHIP 10K 5% 1/10W
R913 1-216-033-00 METAL CHIP 220 5% 1/10W
R914 1-216-295-91 SHORT 0
R915 1-216-081-00 METAL CHIP 22K 5% 1/10W
R916 1-260-087-81 CARBON 100 5% 1/2W
R917 1-216-295-91 SHORT 0
R931 1-216-081-00 METAL CHIP 22K 5% 1/10W
R932 1-216-081-00 METAL CHIP 22K 5% 1/10W
R933 1-216-081-00 METAL CHIP 22K 5% 1/10W
R951 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R952 1-216-045-00 METAL CHIP 680 5% 1/10W
R953 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R954 1-216-138-00 METAL CHIP 3.3 5% 1/8W
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K
RV351 1-238-600-11 RES, ADJ, CARBON 10K
< VIBRATOR >
X510 1-567-098-41 VIBRATOR, CRYSTAL (32.768MHz)
X513 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
**************************************************************
1-675-906-11 5V POWER BOARD
**************
< CAPACITOR >
C101 1-104-664-11 ELECT 47uF 20% 25V
C102 1-126-964-11 ELECT 10uF 20% 50V
C103 1-126-916-11 ELECT 1000uF 20% 6.3V
< CONNECTOR >
* CN101 1-564-507-11 PLUG, CONNECTOR 4P
< DIODE >
D101 8-719-110-12 DIODE MTZJ-T-72-9.1A
MAIN
5V POWER
