82
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PANEL
< IC >
IC101 8-759-496-15 IC BA05ST-V5
< TRANSISTOR >
Q101 8-729-209-15 TRANSISTOR 2SD2012
< RESISTOR >
R101 1-247-807-31 CARBON 100 5% 1/4W
R102 1-249-409-11 CARBON 220 5% 1/4W F
**************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 30% 16V
C804 1-162-306-11 CERAMIC 0.01uF 30% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-109-93 DIODE MTZJ-T-77-6.2C
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-991-33 DIODE 1SS133T-77
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE)
**************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-109-69 DIODE MTZJ-T-77-3.6B
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
A-4426-782-A PANEL BOARD, COMPLETE
*********************
* 4-214-439-11 HOLDER, FL TUBE
4-949-935-41 CUSHION (FL)
< CAPACITOR >
C601 1-124-589-11 ELECT 47uF 20% 16V
C602 1-126-163-11 ELECT 4.7uF 20% 50V
C603 1-162-306-11 CERAMIC 0.01uF 30% 16V
C604 1-162-294-31 CERAMIC 0.001uF 10% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
C607 1-126-160-11 ELECT 1uF 20% 50V
C610 1-124-589-11 ELECT 47uF 20% 16V
C611 1-162-306-11 CERAMIC 0.01uF 30% 16V
C612 1-162-306-11 CERAMIC 0.01uF 30% 16V
C614 1-162-306-11 CERAMIC 0.01uF 30% 6V
C615 1-162-306-11 CERAMIC 0.01uF 30% 16V
C616 1-126-157-11 ELECT 10uF 20% 16V
C617 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C618 1-126-157-11 ELECT 10uF 20% 16V
C619 1-126-157-11 ELECT 10uF 20% 16V
C620 1-126-163-11 ELECT 4.7uF 20% 50V
C625 1-126-157-11 ELECT 10uF 20% 16V
C627 1-162-306-11 CERAMIC 0.01uF 30% 16V
C628 1-126-157-11 ELECT 10uF 20% 16V
C630 1-162-306-11 CERAMIC 0.01uF 30% 16V
C631 1-162-306-11 CERAMIC 0.01uF 30% 16V
C632 1-162-306-11 CERAMIC 0.01uF 30% 6V
C651 1-162-282-31 CERAMIC 100PF 10% 50V
C652 1-162-282-31 CERAMIC 100PF 10% 50V
C653 1-162-282-31 CERAMIC 100PF 10% 50V
C654 1-162-282-31 CERAMIC 100PF 10% 50V
C655 1-162-282-31 CERAMIC 100PF 10% 50V
C656 1-162-282-31 CERAMIC 100PF 10% 50V
C657 1-162-282-31 CERAMIC 100PF 10% 50V
C658 1-162-282-31 CERAMIC 100PF 10% 50V
C659 1-162-282-31 CERAMIC 100PF 10% 50V
C660 1-162-282-31 CERAMIC 100PF 10% 50V
C661 1-162-282-31 CERAMIC 100PF 10% 50V
C662 1-162-282-31 CERAMIC 100PF 10% 50V
C663 1-162-282-31 CERAMIC 100PF 10% 50V
C664 1-162-282-31 CERAMIC 100PF 10% 50V
C665 1-162-282-31 CERAMIC 100PF 10% 50V
C666 1-162-282-31 CERAMIC 100PF 10% 50V
C667 1-162-282-31 CERAMIC 100PF 10% 50V
C668 1-162-282-31 CERAMIC 100PF 10% 50V
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
C702 1-162-294-31 CERAMIC 0.001uF 10% 50V
C703 1-164-159-11 CERAMIC 0.1uF 50V
C711 1-162-294-31 CERAMIC 0.001uF 10% 50V
C712 1-162-305-11 CERAMIC 0.0068uF 30% 16V
MOTOR (TURN)
MOTOR (SLIDE)
5V POWER
