83
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PANEL
C713 1-126-160-11 ELECT 1uF 20% 50V
C714 1-136-495-11 MYLAR 0.068uF 5% 50V
C715 1-124-465-00 ELECT 0.47uF 20% 50V
C716 1-124-465-00 ELECT 0.47uF 20% 50V
C717 1-136-167-00 MYLAR 0.15uF 5% 50V
C718 1-162-294-31 CERAMIC 0.001uF 10% 50V
C719 1-126-160-11 ELECT 1uF 20% 50V
C720 1-161-494-00 CERAMIC 0.022uF 25V
C721 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C722 1-136-495-11 MYLAR 0.068uF 5% 50V
C723 1-124-589-11 ELECT 47uF 20% 16V
C724 1-136-165-00 MYLAR 0.1uF 5% 50V
C725 1-124-589-11 ELECT 47uF 20% 16V
C731 1-162-306-11 CERAMIC 0.01uF 30% 16V
C732 1-124-257-00 ELECT 2.2uF 20% 50V
C733 1-162-294-31 CERAMIC 0.001uF 10% 50V
C734 1-162-215-31 CERAMIC 47PF 5% 50V
C735 1-124-261-00 ELECT 10uF 20% 50V
C736 1-162-290-31 CERAMIC 470PF 10% 50V
C737 1-124-463-00 ELECT 0.1uF 20% 50V
C738 1-124-257-00 ELECT 2.2uF 20% 50V
C739 1-162-215-31 CERAMIC 47PF 5% 50V
C741 1-124-261-00 ELECT 10uF 20% 50V
C742 1-162-282-31 CERAMIC 100PF 10% 50V
C743 1-124-257-00 ELECT 2.2uF 20% 50V
C744 1-162-306-11 CERAMIC 0.01uF 30% 16V
C745 1-124-257-00 ELECT 2.2uF 20% 50V
C747 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN601 1-784-745-11 CONNECTOR, FFC 23P
< DIODE >
D610 8-719-050-84 DIODE RB441Q-40T-72
D611 8-719-073-47 DIODE SML72923C-TP15 (REC/PAUSE START)
D612 8-719-056-13 DIODE SML79423C-TP15 ( ^ CD)
D613 8-719-058-03 DIODE SEL5423E-TP15 (TAPE B ( )
D614 8-719-058-03 DIODE SEL5423E-TP15 (TAPE B 9 )
D615 8-719-058-03 DIODE SEL5423E-TP15 (TAPE A ( )
D616 8-719-058-03 DIODE SEL5423E-TP15 (TAPE A 9 )
D617 8-719-057-97 DIODE SEL5923A-TP15 (PBC OFF)
D618 8-719-057-97 DIODE SEL5923A-TP15 (PBC)
D619 8-719-057-97 DIODE SEL5923A-TP15 (SYNC BASE L)
D620 8-719-057-97 DIODE SEL5923A-TP15 (SYNC BASE H)
D621 8-719-057-97 DIODE SEL5923A-TP15 (SYNC EQ)
D622 8-719-063-93 DIODE SLR325VC-N-T32 (EFFECT)
D623 8-719-057-97 DIODE SEL5923A-TP15 (S VIDEO /VCD)
D624 8-719-063-93 DIODE SLR325VC-N-T32 (NON STOP)
D625 8-719-057-97 DIODE SEL5923A-TP15 (CIMEMA SPACE/DSP)
D626 8-719-057-97 DIODE SEL5923A-TP15 (PRO LOGIC)
D627 8-719-057-97 DIODE SEL5923A-TP15 (GROOVE)
D628 8-719-063-93 DIODE SLR325VC-N-T32 (ENTERY NEXT)
D629 8-719-063-93 DIODE SLR325VC-N-T32
(JOG 0x) )
D630 8-719-057-97 DIODE SEL5923A-TP15 (– 0)
D631 8-719-057-97 DIODE SEL5923A-TP15 (+ ))
D632 8-719-063-93 DIODE SLR325VC-N-T32 (TIMER SELECT)
D701 8-719-109-85 DIODE MTZJ-T-72-5.1B
< GROUND PLATE >
* EP601 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD >
FB601 1-412-473-21 INDUCTOR 0UH
FB602 1-412-473-21 INDUCTOR 0UH
< FLUORESCENT TUBE >
FL601 1-517-831-31 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-589-14 IC TMP88CS76F-6010
IC602 8-749-011-05 IC GP1U28X (REMOCON CONTROL RECEIVER)
IC603 8-759-570-21 IC BA3830F
IC604 8-759-587-81 IC NJU3716M-T2
IC711 8-759-496-40 IC M65850FP
IC712 8-759-636-55 IC M5218AFP
< JACK >
J701 1-785-569-11 JACK (SMALL TYPE) (PHONES)
J711 1-785-569-11 JACK (SMALL TYPE) (MIC2)
J712 1-785-569-11 JACK (SMALL TYPE) (MIC1)
< COIL >
L601 1-410-509-11 INDUCTOR 10uH
L602 1-410-517-11 INDUCTOR 47uH
< TRANSISTOR >
Q601 8-729-118-00 TRANSISTOR 2SB1116-L
Q602 8-729-118-00 TRANSISTOR 2SB1116-L
Q603 8-729-119-78 TRANSISTOR 2SC403SP-51
Q604 8-729-422-57 TRANSISTOR UN4111
Q605 8-729-422-57 TRANSISTOR UN4111
Q606 8-729-900-80 TRANSISTOR DTC114ES
Q607 8-729-900-74 TRANSISTOR DTC143TS
Q608 8-729-900-74 TRANSISTOR DTC143TS
Q609 8-729-900-74 TRANSISTOR DTC143TS
Q610 8-729-900-74 TRANSISTOR DTC143TS
Q611 8-729-900-74 TRANSISTOR DTC143TS
Q612 8-729-900-74 TRANSISTOR DTC143TS
Q613 8-729-900-74 TRANSISTOR DTC143TS
< RESISTOR >
R600 1-247-903-00 CARBON 1M 5% 1/4W
R601 1-247-807-31 CARBON 100 5% 1/4W
R602 1-249-429-11 CARBON 10K 5% 1/4W
R603 1-247-807-31 CARBON 100 5% 1/4W
R604 1-247-807-31 CARBON 100 5% 1/4W
R605 1-249-429-11 CARBON 10K 5% 1/4W
R606 1-249-401-11 CARBON 47 5% 1/4W F
R607 1-247-893-11 CARBON 390K 5% 1/4W
R608 1-247-893-11 CARBON 390K 5% 1/4W
R609 1-249-441-11 CARBON 100K 5% 1/4W
R610 1-249-429-11 CARBON 10K 5% 1/4W
R611 1-249-441-11 CARBON 100K 5% 1/4W
R612 1-249-401-11 CARBON 47 5% 1/4W F
To Next Page
