Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
SENSOR
R735 1-249-420-11 CARBON 1.8K 5% 1/4W F
R741 1-249-421-11 CARBON 2.2K 5% 1/4W F
R742 1-249-421-11 CARBON 2.2K 5% 1/4W F
R743 1-247-807-31 CARBON 100 5% 1/4W
R768 1-249-417-11 CARBON 1K 5% 1/4W F
R769 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV711 1-225-739-11 RES, VAR CARBON 50K (ECHO LEVEL)
RV712 1-225-739-11 RES, VAR CARBON 50K (MIC LEVEL)
< SWITCH >
S601 1-473-534-11 ENCODER, ROTARY (JOG 0x) )
S602 1-473-392-11 ENCODER, ROTARY (VOLUME)
S611 1-762-875-21 SWITCH, KEYBOARD (SYNC BASS)
S612 1-762-875-21 SWITCH, KEYBOARD (SYNC EQ)
S613 1-762-875-21 SWITCH, KEYBOARD (KERAOKE PON/MPX)
S614 1-762-875-21 SWITCH, KEYBOARD (NON STOP)
S615 1-762-875-21 SWITCH, KEYBOARD (CIMEMA SPACE/DSP)
S616 1-762-875-21 SWITCH, KEYBOARD (DBFB)
S617 1-762-875-21 SWITCH, KEYBOARD (ENTERY/NEXT)
S618 1-762-875-21 SWITCH, KEYBOARD (+ ))
S619 1-762-875-21 SWITCH, KEYBOARD (– 0)
S620 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S621 1-762-875-21 SWITCH, KEYBOARD (FLASH)
S622 1-762-875-21 SWITCH, KEYBOARD (REPEAT STEREO/MONO)
S623 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE DOLBY NR)
S624 1-762-875-21 SWITCH, KEYBOARD
(EDIT DIRECTION TUNER MEMORY)
S625 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S626 1-762-875-21 SWITCH, KEYBOARD (HI DUB)
S627 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S628 1-762-875-21 SWITCH, KEYBOARD (LOOP)
S629 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S630 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM ANALYZER)
S632 1-762-875-21 SWITCH, KEYBOARD (SELECT)
S633 1-762-875-21 SWITCH, KEYBOARD (RETURN)
S634 1-762-875-21 SWITCH, KEYBOARD (PREV)
S635 1-762-875-21 SWITCH, KEYBOARD (NEXT)
S636 1-762-875-21 SWITCH, KEYBOARD (DVD 5.1CH)
S637 1-762-875-21 SWITCH, KEYBOARD (PRO LOGIC)
S638 1-762-875-21 SWITCH, KEYBOARD (TIMER SELECT)
S639 1-762-875-21 SWITCH, KEYBOARD (P.FILE MEMORY)
S640 1-762-875-21 SWITCH, KEYBOARD (GEQ CONTROL)
S641 1-762-875-21 SWITCH, KEYBOARD (FILE SELECT)
S642 1-762-875-21 SWITCH, KEYBOARD (EFFECT)
S643 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S644 1-762-875-21 SWITCH, KEYBOARD (CD ^)
S645 1-762-875-21 SWITCH, KEYBOARD (p)
S646 1-762-875-21 SWITCH, KEYBOARD (TAPE B 9)
S647 1-762-875-21 SWITCH, KEYBOARD (TAPE B ()
S648 1-762-875-21 SWITCH, KEYBOARD (TAPE A 9)
S649 1-762-875-21 SWITCH, KEYBOARD (TAPE A ()
S650 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S651 1-762-875-21 SWITCH, KEYBOARD (CLOCK TIMER SET)
< VIBRATOR >
X601 1-781-312-11 VIBRATOR, CERAMIC (12.5MHz)
**************************************************************
* 1-658-576-11 SENSOR BOARD
************
< IC >
IC702 8-749-924-18 PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W F
R702 1-249-407-11 CARBON 150 5% 1/4W F
**************************************************************
* 1-672-369-11 TRANS BOARD
************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C971 1-128-563-11 ELECT 100uF 20% 100V
C972 1-126-960-11 ELECT 1uF 20% 50V
C973 1-126-948-11 ELECT 100uF 20% 35V
< CONNECTOR >
CN951 1-564-321-00 PIN, CONNECTOR 2P
* CN952 1-564-527-11 PLUG, CONNECTOR 12P
CN971 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE)3P
< DIODE >
D971 8-719-024-99 DIODE 11ES2-NTA2B
D972 8-719-986-60 DIODE HZS27-3LTA
D973 8-719-109-63 DIODE MTZJ-T-72-3.0B
< FUSE >
! F953 1-532-465-31 FUSE (T2.5AL/250V)
! F961 1-533-949-31 FUSE (T8AL/250V)
! F962 1-533-949-31 FUSE (T8AL/250V)
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
! R951 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R952 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R971 1-216-479-11 METAL OXIDE 560 5% 3W F
R972 1-249-429-11 CARBON 10K 5% 1/4W
R973 1-249-429-11 CARBON 10K 5% 1/4W
R974 1-247-807-31 CARBON 100 5% 1/4W
R975 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
PANEL
TRANS
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
