86
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
A-4724-927-A VIDEO BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C104 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C105 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C106 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C107 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C501 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C503 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C504 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C505 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C510 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C511 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C512 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C513 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C514 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C515 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C516 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C517 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C518 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C519 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C520 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C521 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C522 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C523 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C524 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C525 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C526 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C527 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C528 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C529 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C530 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C531 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C532 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C533 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C534 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C535 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C536 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C537 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C538 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C539 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C540 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C541 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C543 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C544 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C545 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C546 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C547 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C548 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C549 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C550 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C551 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C552 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C554 1-104-527-11 FILM CHIP 100PF 5% 50V
C555 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C556 1-104-527-11 FILM CHIP 100PF 5% 50V
C557 1-104-527-11 FILM CHIP 100PF 5% 50V
C558 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C559 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C560 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C561 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C562 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C563 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C564 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C565 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C566 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C567 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C570 1-117-681-11 ELECT CHIP 100uF 20% 16V
C603 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C604 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C605 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C606 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C607 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C608 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C609 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C610 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C611 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C612 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
< CONNECTOR >
CN501 1-770-708-11 CONNECTOR, FFC/FPC 25P
CN502 1-793-580-11 CONNECTOR (LIF) (NON-Z1F)(15P)
CN505 1-774-766-11 CONNECTOR, FFC/FPC 11P
< TRIMMER >
CT503 1-141-539-11 CAP, ADJ 10PF
< DIODE >
D502 8-719-018-51 DIODE CL-170R-CD-T
< FERRITE BEAD >
FB501 1-469-145-21 FERRITE 0UH
FB502 1-469-145-21 FERRITE 0UH
FB503 1-469-145-21 FERRITE 0UH
< IC >
IC503 8-759-530-30 IC TC74VHCU04FT(EL)
IC504 8-759-460-72 IC BA033FP-E2
IC505 8-759-646-72 IC M30624FGFP
IC506 8-759-644-61 IC CL8830-PD0
IC507 8-759-573-19 IC MSM56V16160D-10TS-K
IC508 8-759-646-85 IC MSM27C401CZ-A4GSKDR1
IC509 8-759-535-62 IC PCM1727E-2/T2
IC510 8-759-530-30 IC TC74VHCU04FT(EL)
IC511 8-759-646-38 IC BU2990-03FV
IC514 8-759-643-06 IC BU1427K
IC515 8-759-701-39 IC NJM2100M(TE2)
VIDEO
