Sony HCD-VX880AV - Page 87

87
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
VIDEO
< JACK >
J501 1-537-943-11 TERMINAL, S (S VIDEO OUT)
J502 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< JUMPER RESISTOR >
JW503 1-216-295-91 SHORT 0
JW504 1-216-295-91 SHORT 0
JW506 1-216-295-91 SHORT 0
JW514 1-216-295-91 SHORT 0
JW515 1-216-295-91 SHORT 0
JW526 1-216-295-91 SHORT 0
JW527 1-216-295-91 SHORT 0
JW538 1-216-295-91 SHORT 0
JW539 1-216-295-91 SHORT 0
JW541 1-216-295-91 SHORT 0
JW542 1-216-295-91 SHORT 0
JW543 1-216-295-91 SHORT 0
JW544 1-216-295-91 SHORT 0
JW545 1-216-295-91 SHORT 0
JW546 1-216-295-91 SHORT 0
JW547 1-216-295-91 SHORT 0
JW548 1-216-295-91 SHORT 0
< COIL >
L501 1-216-296-91 SHORT 0
L502 1-216-296-91 SHORT 0
L503 1-410-370-31 INDUCTOR CHIP 1.2uH
L504 1-410-375-11 INDUCTOR CHIP 3.3uH
L505 1-410-370-31 INDUCTOR CHIP 1.2uH
L506 1-216-296-91 SHORT 0
L507 1-216-296-91 SHORT 0
L508 1-216-296-91 SHORT 0
L509 1-216-296-91 SHORT 0
L517 1-216-296-91 SHORT 0
L518 1-216-296-91 SHORT 0
L519 1-410-374-11 INDUCTOR CHIP 2.7uH
L520 1-410-374-11 INDUCTOR CHIP 2.7uH
L521 1-410-374-11 INDUCTOR CHIP 2.7uH
< RESISTOR >
R101 1-216-073-00 METAL CHIP 10K 5% 1/10W
R102 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R103 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R104 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R105 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R201 1-216-073-00 METAL CHIP 10K 5% 1/10W
R202 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R203 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R501 1-216-025-91 RES,CHIP 100 5% 1/10W
R502 1-216-025-91 RES,CHIP 100 5% 1/10W
R503 1-216-025-91 RES,CHIP 100 5% 1/10W
R504 1-216-073-00 METAL CHIP 10K 5% 1/10W
R505 1-216-073-00 METAL CHIP 10K 5% 1/10W
R506 1-216-025-91 RES,CHIP 100 5% 1/10W
R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-025-91 RES,CHIP 100 5% 1/10W
R509 1-216-025-91 RES,CHIP 100 5% 1/10W
R510 1-216-073-00 METAL CHIP 10K 5% 1/10W
R511 1-216-073-00 METAL CHIP 10K 5% 1/10W
R512 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R513 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R514 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R515 1-216-073-00 METAL CHIP 10K 5% 1/10W
R516 1-216-025-91 RES,CHIP 100 5% 1/10W
R517 1-216-025-91 RES,CHIP 100 5% 1/10W
R518 1-216-025-91 RES,CHIP 100 5% 1/10W
R519 1-216-073-00 METAL CHIP 10K 5% 1/10W
R520 1-216-073-00 METAL CHIP 10K 5% 1/10W
R521 1-216-073-00 METAL CHIP 10K 5% 1/10W
R522 1-216-025-91 RES,CHIP 100 5% 1/10W
R524 1-216-025-91 RES,CHIP 100 5% 1/10W
R525 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R530 1-216-073-00 METAL CHIP 10K 5% 1/10W
R531 1-216-073-00 METAL CHIP 10K 5% 1/10W
R532 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R533 1-216-073-00 METAL CHIP 10K 5% 1/10W
R534 1-216-073-00 METAL CHIP 10K 5% 1/10W
R537 1-216-073-00 METAL CHIP 10K 5% 1/10W
R538 1-216-025-91 RES,CHIP 100 5% 1/10W
R539 1-216-025-91 RES,CHIP 100 5% 1/10W
R540 1-216-025-91 RES,CHIP 100 5% 1/10W
R541 1-216-025-91 RES,CHIP 100 5% 1/10W
R542 1-216-295-91 SHORT 0
R543 1-216-295-91 SHORT 0
R544 1-216-295-91 SHORT 0
R545 1-216-029-00 METAL CHIP 150 5% 1/10W
R546 1-216-121-91 RES,CHIP 1M 5% 1/10W
R547 1-216-025-91 RES,CHIP 100 5% 1/10W
R548 1-216-025-91 RES,CHIP 100 5% 1/10W
R549 1-216-025-91 RES,CHIP 100 5% 1/10W
R550 1-216-025-91 RES,CHIP 100 5% 1/10W
R551 1-216-025-91 RES,CHIP 100 5% 1/10W
R552 1-216-025-91 RES,CHIP 100 5% 1/10W
R553 1-216-025-91 RES,CHIP 100 5% 1/10W
R554 1-216-025-91 RES,CHIP 100 5% 1/10W
R555 1-216-025-91 RES,CHIP 100 5% 1/10W
R556 1-216-295-91 SHORT 0
R557 1-216-295-91 SHORT 0
R558 1-216-295-91 SHORT 0
R560 1-216-073-00 METAL CHIP 10K 5% 1/10W
R561 1-216-295-91 SHORT 0
R562 1-216-022-00 METAL CHIP 75 5% 1/10W
R563 1-216-022-00 METAL CHIP 75 5% 1/10W
R564 1-216-022-00 METAL CHIP 75 5% 1/10W
R565 1-216-073-00 METAL CHIP 10K 5% 1/10W
R566 1-216-073-00 METAL CHIP 10K 5% 1/10W
R567 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R568 1-216-295-91 SHORT 0
R569 1-216-073-00 METAL CHIP 10K 5% 1/10W
R599 1-216-049-91 RES,CHIP 1K 5% 1/10W
R600 1-216-025-91 RES,CHIP 100 5% 1/10W
R605 1-216-017-91 RES,CHIP 47 5% 1/10W
R606 1-216-017-91 RES,CHIP 47 5% 1/10W
R607 1-216-017-91 RES,CHIP 47 5% 1/10W
R608 1-216-017-91 RES,CHIP 47 5% 1/10W
