HCD-VX880AV
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
VIDEO
R609 1-216-017-91 RES,CHIP 47 5% 1/10W
R610 1-216-017-91 RES,CHIP 47 5% 1/10W
R611 1-216-017-91 RES,CHIP 47 5% 1/10W
R612 1-216-017-91 RES,CHIP 47 5% 1/10W
R613 1-216-017-91 RES,CHIP 47 5% 1/10W
R614 1-216-017-91 RES,CHIP 47 5% 1/10W
R615 1-216-017-91 RES,CHIP 47 5% 1/10W
R616 1-216-017-91 RES,CHIP 47 5% 1/10W
R617 1-216-017-91 RES,CHIP 47 5% 1/10W
R618 1-216-017-91 RES,CHIP 47 5% 1/10W
R619 1-216-017-91 RES,CHIP 47 5% 1/10W
R620 1-216-017-91 RES,CHIP 47 5% 1/10W
R621 1-216-017-91 RES,CHIP 47 5% 1/10W
R622 1-216-017-91 RES,CHIP 47 5% 1/10W
R623 1-216-017-91 RES,CHIP 47 5% 1/10W
R624 1-216-017-91 RES,CHIP 47 5% 1/10W
R625 1-216-017-91 RES,CHIP 47 5% 1/10W
R626 1-216-017-91 RES,CHIP 47 5% 1/10W
R627 1-216-017-91 RES,CHIP 47 5% 1/10W
R628 1-216-017-91 RES,CHIP 47 5% 1/10W
R629 1-216-017-91 RES,CHIP 47 5% 1/10W
R630 1-216-017-91 RES,CHIP 47 5% 1/10W
R631 1-216-017-91 RES,CHIP 47 5% 1/10W
R632 1-216-017-91 RES,CHIP 47 5% 1/10W
R633 1-216-017-91 RES,CHIP 47 5% 1/10W
R634 1-216-017-91 RES,CHIP 47 5% 1/10W
R635 1-216-017-91 RES,CHIP 47 5% 1/10W
R636 1-216-017-91 RES,CHIP 47 5% 1/10W
R637 1-216-017-91 RES,CHIP 47 5% 1/10W
R638 1-216-017-91 RES,CHIP 47 5% 1/10W
R639 1-216-017-91 RES,CHIP 47 5% 1/10W
R640 1-216-017-91 RES,CHIP 47 5% 1/10W
R641 1-216-017-91 RES,CHIP 47 5% 1/10W
R642 1-216-017-91 RES,CHIP 47 5% 1/10W
R643 1-216-017-91 RES,CHIP 47 5% 1/10W
R644 1-216-017-91 RES,CHIP 47 5% 1/10W
R645 1-216-017-91 RES,CHIP 47 5% 1/10W
R646 1-216-017-91 RES,CHIP 47 5% 1/10W
R1517 1-216-033-00 METAL CHIP 220 5% 1/10W
R1518 1-216-033-00 METAL CHIP 220 5% 1/10W
R1519 1-216-033-00 METAL CHIP 220 5% 1/10W
R1520 1-216-033-00 METAL CHIP 220 5% 1/10W
R1521 1-216-033-00 METAL CHIP 220 5% 1/10W
R1522 1-216-033-00 METAL CHIP 220 5% 1/10W
R1523 1-216-033-00 METAL CHIP 220 5% 1/10W
R1524 1-216-033-00 METAL CHIP 220 5% 1/10W
< SWITCH >
S501 1-571-395-11 SWITCH, SLIDE (SYSTEM SELECT)
< VIBRATOR >
X501 1-767-510-11 VIBRATOR, CERAMIC (10MHz)
X503 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
**************************************************************
MISCELLANEOUS
*************
5 1-693-381-11 TUNER UNIT (FM/AM)
9 1-791-517-11 WIRE (FLAT TYPE) (15 CORE)
10 1-775-229-11 WIRE (FLAT TYPE) (25 CORE)
55 1-773-008-11 WIRE (FLAT TYPE) (15 CORE) (140 mm)
56 1-773-049-11 WIRE (FLAT TYPE) (17 CORE)
! 59 1-782-464-21 CORD, POWER
62 1-773-023-11 WIRE (FLAT TYPE) (15 CORE) (310 mm)
116 1-773-189-11 WIRE (FLAT TYPE) (23 CORE)
121 1-674-232-11 PUSH CATCH STOP BOARD
257 1-452-925-21 MAGNET ASSY
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
FL601 1-517-831-31 INDICATOR TUBE, FLUORESCENT
HP101 A-2056-681-B DECK (A) ASSY, HEAD
HRPE101 A-2056-682-B DECK (B) ASSY, HEAD
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-4917-523-3 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M701 A-4672-004-A MOTOR ASSY (TURN)
M801 A-4672-004-A MOTOR ASSY (SLIDE)
M901 1-763-072-11 FAN, D.C.
S811 1-473-335-11 ENCODER, ROTARY
! T951 1-433-555-21 TRANSFORMER, POWER
**************************************************************
**************
HARDWARE LIST
**************
#1 7-685-871-01 SCREW +BVTT 3X6 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-881-09 SCREW +BVTT 4X8 (S)
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#5 7-685-852-04 SCREW +BVTT 2X5 (S)
#6 7-621-775-10 SCREW +B 2.6X4
#7 7-685-872-09 SCREW +BVTT 3X8 (S)
#8 7-685-851-04 SCREW +BVTT 2X4 (S)
#9 7-628-254-15 SCREW +PS 2.6X6
#10 7-628-254-50 SCREW +PS 2.6X16
#11 7-685-861-01 SCREW +BVTT 2.6X5 (S)
#12 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
