1-4. Writing and Rewriting the PLD
Internal Data
HDCU3300 uses the PLD (Programmable Logic Device)
that supports the e-Production (EPR) system to write and
rewrite the internal data.
If the parts listed below needs to be replaced or if PLD
needs to be upgraded, contact your local Sony Sales
Office/Service Center.
n
The part number of PLD (or ROM for PLD) in which data
is not written yet, is shown in “ Spare Parts”.
Therefore, if part replacement is required, write the data by
the following procedure.
In the case of the PLD type that runs on the program stored
in external ROM, the PLD has only to be replaced and data
needs not to be written only if the specific PLD is defective.
e-Production system has the advantages shown
below.
. To write/rewrite the PLD internal data:
1. The standard fixture (cable) can be used.
2. The standard software (PLD Download Tool) can be
used.
. The PLD internal data is controlled in the Sony Database
Server under the name Project file (E_xxx_xxx_xx_xx).
. The printed circuit board is equipped with the standard
connector (EPR connector) to write the PLD internal
data. The indication “EPR” is shown on the printed
circuit board.
Corresponding PLDs
Board name
PLD/ROM EPR connector Version Project file No.
SOFT
AT-167S V1.10
CPU-395 V1.05
PLD
AT-167S
IC601
*1
, IC603 CN601 V1.09 E_000_001_93_16
AVP-6
IC302, IC310
*2
CN3 V1.02 E_000_001_94_12
CPU-395
IC312
*3
, IC315 CN301 V1.00 E_000_002_00_02
DTX-5
IC401, IC505
*4
,
IC506
*4
CN501 V1.08 E_000_001_95_18
DPR-271A
IC211, IC401
*5
, CN301 V1.06 E_000_002_02_05
DPR-271B
IC211, IC401
*5
, CN301 V1.07 E_000_003_38_05
DRX-5
IC211, IC213
*6
,
IC214
*6
, IC215
*6
CN3 V1.05 E_000_001_96_19
SDP-15
*10
IC203, IC312,
IC307
*7
CN301 V1.01 E_000_002_01_04
OTR-1
IC1, IC601
*8
, CN601 V1.02 E_000_003_37_01
EN-159A/159B
(HKCU1001/1003)
IC210, IC501,
IC502
*9
, IC504
*9
CN501 V1.02 E_000_001_98_12
*1 : IC601/AT-167S is a ROM for IC603/AT-167S.
*2 : IC310/AVP-6 is a ROM for IC302/AVP-6.
*3 : IC312/CPU-395 is a ROM for IC315/CPU-395.
*4 : IC505, IC506/DTX-5 is a ROM for IC401/DTX-5.
*5 :
IC302, 303, 304, 305, 306/DPR-271 is a ROM for IC211, IC401/DPR-
271.
*6 : IC213, IC214,IC215/DRX-5 is a ROM for IC211/DRX-5.
*7 :
IC307/SDP-15 is a ROM for IC203, IC312/SPD-15.
*8 : IC601/OTR-1 is a ROM for IC1/OTR-1.
*9 : IC502, IC504/EN-159A/159B is a ROM for IC210, IC501/EN-159A/
159B.
*10 : The data in the PLD of the SDP-15 board can also be written or
rewritten via the AVP-6 board. Turn on switch S4-8 on the AVP-6
board.
n
After having written or rewritten the data in the PLD of the
SDP-15 board via the AVP-6 board, turn off switch S4-8
on the AVP-6 board.
