3-1-4. Initialization Settings
HDCU3300
n
When changing the switch settings from the customer’s
setting positions, it is recommended to write down the
customer’s setting positions in the following table. After
completing the adjustment, be sure to return the switches
to the customer’s setting positions.
Board Switch Setting Customer
during setting
adjustment
AU-302 S2 PROD
S4 CARBON
AVP-6 S500 0 dB
S501 0 dB
S600 RTS
S601 RTS
S602 RTS
S603 RTS
Set the switches other than the above to the state when shipped from the
factory.
For details of the switch settings, refer to Section 1-6, “On-board Indicator/
Switch/Volume Functions” of the separate Installation Manual.
When using the MSU-900:
. Power supply and signal selector block
ALL button → OFF (Dark)
CAM PW button → ON (Lit)
TEST1 button → OFF (Dark)
TEST2 button → OFF (Dark)
BARS button → OFF (Dark)
CLOSE button → ON (Lit)
. Camera/CCU circuit ON/OFF block
DETAIL OFF button → OFF (Lit)
KNEE OFF button → ON (Dark)
AUTO KNEE button → OFF (Dark)
MATRIX OFF button → OFF (Lit)
. AUTO SETUP block
LEVEL button → OFF (Dark)
WHITE button → OFF (Dark)
BLACK button → OFF (Dark)
. Others
GAMMA OFF button → OFF (Dark)
MASTER GAIN selector button → 0
When using the MSU-950:
. Power supply and signal selector block
ALL button → OFF (Dark)
CAM PW button → ON (Lit)
TEST button → OFF (Dark)
BARS button → OFF (Dark)
CLOSE button → ON (Lit)
. AUTO SETUP block
LEVEL button → OFF (Dark)
WHITE button → OFF (Dark)
BLACK button → OFF (Dark)
. Others
GAMMA OFF
*
→ ON
(Not highlighted)
MASTER GAIN
*
→ 0 (0 dB)
* : Press the function button and select it on the function menu display.
