Sony HDCU3300 - Connection of Equipment

3-2 (E)
HDCU3300/MM (J,E)
3-1-3. Connection of Equipment
Adjusting the HDCU3300
Adjusting the HKCU1001/1003
OPTICAL FIBER
CABLE
HD CAMERA CONTROL UNIT
HDCU3300
Measure
HD COLOR CAMERA
HDC3300
CCA-5 CABLE
(max. 200m)
MASTER SETUP UNIT
MSU-900/950
OPTICAL FIBER
CABLE
CCA-5 CABLE
(max. 200m)
MASTER SETUP UNIT
MSU-900/950
HD CAMERA CONTROL UNIT
HDCU3300
SD ENCODER UNIT
HKCU1001
WF/VDA-64
75 Z
75 Z
SD Waveform/
Vector monitor
SD Signal genarator
REF IN/CN-2224
+
MULTI INTERFACE UNIT
HKCU1003
or
HD COLOR CAMERA
HDC3300
