43
KDL-26S3000/32S3000/40S3000/46S3000
KDL-26S3000/32S3000/40S3000/46S3000
KDL-32S3000 ONLY
Route/Dress Harnesses connected to
Core Block as Shown
NOTE Order & Direction of Cables in
plastic Clip on Shield Case.
OPERATION PROCESS
2
3
1
1
Keep Cables BELOW level
of Shield Case (Pinch Points)
NOTE order and direction of cables!
DRESS CABLES 1st
DRESS CABLES 2nd
DRESS CABLES 3rd
DRESS CABLES 4th
DRESS CABLES LAST
ON TOP ALL CABLES.
CORE BLOCK HARNESS
