44
KDL-26S3000/32S3000/40S3000/46S3000
KDL-26S3000/32S3000/40S3000/46S3000
KDL-32S3000 ONLY
Route/Dress Core-Block cables as shown
Put Attention on DIRECTION of cables
in G-Bracket.
Put Attention on the position of the Sheet Core C
and routing of the Cables between Core Block
and G1-Bracket.
OPERATION PROCESS
NOTE direction of wires dressed in G-Bracket.
1
1
NOTE Routing of cables and position
of Sheet Core C.
CORE BLOCK HARNESS (CONTINUED)
To Next Page
