KV-13FM13 / 13FM14
NOTE: The components identiÞ ed by shading
and
!
mark are critical for safety. Replace only
with part number speciÞ ed.
NOTE: Les composants identiÞ es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero speciÞ e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
! R616 1-260-302-51 CARBON 6.8 5% 1/2W
R617 1-216-009-91 RES-CHIP 22 5% 1/10W
! R626 1-220-926-11 FUSIBLE 0.47 10% 1/2W
R627 1-215-483-00 METAL 390K 1% 1/4W
R630 1-249-421-11 CARBON 2.2K 5% 1/4W
! R632 1-216-361-00 METAL OXIDE 0.22 5% 2W
R633 1-249-415-11 CARBON 680 5% 1/4W
R634 1-216-073-00 RES-CHIP 10K 5% 1/10W
R635 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R638 1-249-399-11 CARBON 33 5% 1/4W
R639 1-249-421-11 CARBON 2.2K 5% 1/4W
R640 1-249-417-11 CARBON 1K 5% 1/4W
! R641 1-216-369-00 METAL OXIDE 1 5% 2W
R642 1-216-089-11 RES-CHIP 47K 5% 1/10W
R643 1-249-419-11 CARBON 1.5K 5% 1/4W
R644 1-247-843-11 CARBON 3.3K 5% 1/4W
R645 1-215-898-11 METAL OXIDE 10K 5% 2W
R646 1-249-419-11 CARBON 1.5K 5% 1/4W
R648 1-215-908-00 METAL OXIDE 33 5% 3W
R650 1-216-387-11 METAL OXIDE 0.68 5% 3W
R653 1-216-049-11 RES-CHIP 1K 5% 1/10W
R655 1-216-049-11 RES-CHIP 1K 5% 1/10W
R656 1-249-429-11 CARBON 10K 5% 1/4W
R658 1-216-387-11 METAL OXIDE 0.68 5% 3W
R659 1-215-857-11 METAL OXIDE 10 5% 1W
! R660 1-215-924-00 METAL OXIDE 15K 5% 3W
R661 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R663 1-216-081-00 RES-CHIP 22K 5% 1/10W
RELAY
! RY601 1-755-198-11 RELAY
! RY602 1-755-266-11 RELAY, AC POWER
SWITCH
SW502 1-572-707-11 SWITCH LEVER
TRANSFORMER
! T501 1-435-374-11 TRANSFORMER, FERRITE (HDT)
! T505 1-453-339-11 FBT ASSY NX-1912//M3E4
! T602 1-431-419-11 TRANSFORMER, LINE FILTER
! T603 1-433-806-11 TRANSFORMER, REGULAT
! T604 1-431-852-11 TRANSFORMER, CONVERTER (SRT)
THERMISTOR
! TH601 1-803-586-11 THERMISTOR, NTC
THERMISTOR
! THP601 1-809-539-11 THERMISTOR, POSITIVE
TUNER
! TU101 8-598-501-30 TUNER, FSS BTF-FA402
VARISTOR
! VDR601 1-803-585-11 VARISTOR ENE271D-10A
MB
* A-1304-197-A MB (VAR) BOARD, MOUNTED
CAPACITOR
C1005 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1008 1-126-964-11 ELECT 10µF 20% 50V
C1010 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C1011 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1012 1-126-960-11 ELECT 1µF 20% 50V
C1013 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1014 1-130-495-00 MYLAR 0.1µF 5% 50V
C1015 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C1016 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C1018 1-126-960-11 ELECT 1µF 20% 50V
C1019 1-104-664-11 ELECT 47µF 20% 25V
C1020 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C1021 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1022 1-163-135-00 CERAMIC CHIP 560pF 5% 50V
C1023 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1024 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1026 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1027 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C1028 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1029 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C1030 1-126-963-11 ELECT 4.7µF 20% 50V
C1031 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1032 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C1034 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1035 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C1041 1-126-941-11 ELECT 470µF 20% 25V
C1042 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C1043 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C1048 1-137-194-81 FILM 0.47µF 5% 50V
C1049 1-163-017-00 CERAMIC CHIP .0047µF 10% 50V
C1050 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C1053 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C1054 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
