— 44 —
KV-13FM13 / 13FM14
REF.NO. PART NO. DESCRIPTION VALUES
REF.NO. PART NO. DESCRIPTION VALUES
C1055 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C1056 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1058 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1060 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1066 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1068 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1071 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1072 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1073 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1074 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1075 1-126-941-11 ELECT 470µF 20% 25V
C1076 1-126-959-11 ELECT 0.47µF 20% 50V
C1077 1-126-964-11 ELECT 10µF 20% 50V
C1099 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1304 1-126-959-11 ELECT 0.47µF 20% 50V
C1305 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1306 1-126-933-11 ELECT 100µF 20% 16V
C1307 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1308 1-126-933-11 ELECT 100µF 20% 16V
C1309 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1310 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1311 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C1313 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1315 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1320 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1321 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1322 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1323 1-126-933-11 ELECT 100µF 20% 16V
C1324 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1325 1-163-123-00 CERAMIC CHIP 180pF 5% 50V
C1326 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1327 1-126-933-11 ELECT 100µF 20% 16V
C1328 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
C1329 1-163-010-11 CERAMIC CHIP 0.0012µF 10% 50V
C1330 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C1331 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1332 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1334 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1335 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1336 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1339 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1340 1-126-963-11 ELECT 4.7µF 20% 50V
C1341 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1342 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1343 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C1344 1-126-941-11 ELECT 470µF 20% 25V
C1345 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1349 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1350 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1351 1-126-963-11 ELECT 4.7µF 20% 50V
C1352 1-104-664-11 ELECT 47µF 20% 25V
C1353 1-126-964-11 ELECT 10µF 20% 50V
C1354 1-137-194-81 FILM 0.47µF 5% 50V
C1355 1-126-767-11 ELECT 1000µF 20% 16V
C1356 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C1357 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C1358 1-126-963-11 ELECT 4.7µF 20% 50V
C1359 1-126-964-11 ELECT 10µF 20% 50V
C1361 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C1364 1-163-233-11 CERAMIC CHIP 18pF 5% 50V
C1366 1-126-964-11 ELECT 10µF 20% 50V
C1375 1-163-034-00 CERAMIC CHIP 0.033µF 50V
C1376 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1377 1-126-960-11 ELECT 1µF 20% 50V
C1378 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C1379 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1380 1-163-003-11 CERAMIC CHIP 330pF 10% 50V
C1381 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C1382 1-126-964-11 ELECT 10µF 20% 50V
C1385 1-126-964-11 ELECT 10µF 20% 50V
C1386 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C1387 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C1392 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C1394 1-104-664-11 ELECT 47µF 20% 25V
C1399 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
CONNECTOR
* CN1001 1-564-511-11 PLUG,CONNECTOR 8P
* CN1002 1-560-124-00 PLUG,CONNECTOR (2.5MM) 4P
CN1003 1-573-301-21 CONNECTOR, BOARD TO BOARD 20P
CN1004 1-573-301-21 CONNECTOR, BOARD TO BOARD 20P
CN1303 1-900-805-12 CONNECTOR ASSY 9P BOARD
DIODE
D1001 8-719-069-54 DIODE UDZSTE-175.1B
D1005 8-719-109-89 DIODE MTZJ-T-77-5.6C
D1006 8-719-073-01 DIODE MA111-TX
D1010 8-719-069-60 DIODE UDZSTE-179.1B
D1011 8-719-073-01 DIODE MA111-TX
D1012 8-719-073-01 DIODE MA111-TX
D1013 8-719-069-60 DIODE UDZSTE-179.1B
D1014 8-719-073-01 DIODE MA111-TX
D1301 8-719-914-44 DIODE DAP202K-T-146
D1310 8-719-069-54 DIODE UDZSTE-175.1B
MB
