Sony MXD-D40 - Page 93

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
93
MXD-D40
C818 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C819 1-104-665-11 ELECT 100uF 20% 10V
C820 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C821 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C822 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C823 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C827 1-126-791-11 ELECT 10uF 20% 16V
C828 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C829 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C830 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C842 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C850 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C851 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C852 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C853 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C860 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C861 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN300 1-506-468-11 PIN, CONNECTOR 3P
* CN301 1-568-954-11 PIN, CONNECTOR 5P
CN302 1-778-692-11 CONNECTOR, FFC/FPC 21P
CN303 1-784-376-11 CONNECTOR, FFC/FPC 17P
CN304 1-784-384-11 CONNECTOR, FFC/FPC 27P
CN305 1-793-990-11 CONNECTOR, FFC/FPC 18P
CN503 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
CN504 1-506-469-11 PIN, CONNECTOR 4P
CN505 1-568-683-11 PIN, CONNECTOR (PC BAORD) 2P
< DIODE >
D100 8-719-800-76 DIODE 1SS226
D200 8-719-800-76 DIODE 1SS226
D300 8-719-801-78 DIODE 1SS184
D302 8-719-820-05 DIODE 1SS181
D303 8-719-820-05 DIODE 1SS181
D400 8-719-422-41 DIODE MA8051-L-TX
D501 8-719-200-02 DIODE 10E-2
D502 8-719-200-02 DIODE 10E-2
D503 8-719-200-02 DIODE 10E-2
D504 8-719-200-02 DIODE 10E-2
D505 8-719-200-02 DIODE 10E-2
D506 8-719-200-02 DIODE 10E-2
D507 8-719-200-02 DIODE 10E-2
D508 8-719-200-02 DIODE 10E-2
D509 8-719-423-07 DIODE MA8100-L-TX
D510 8-719-200-02 DIODE 10E-2
D511 8-719-200-02 DIODE 10E-2
D512 8-719-200-02 DIODE 10E-2
D513 8-719-200-02 DIODE 10E-2
D514 8-719-200-02 DIODE 10E-2
D516 8-719-421-18 DIODE MA8033-L
D519 8-719-975-40 DIODE RB411D
D520 8-719-975-40 DIODE RB411D
D521 8-719-975-40 DIODE RB411D
D522 8-719-975-40 DIODE RB411D
D523 8-719-074-34 DIODE RB495D-T146
D524 8-719-988-61 DIODE 1SS355TE-17
D526 8-719-988-61 DIODE 1SS355TE-17
< GROUND TERMINAL >
EP300 1-537-771-21 TERMINAL BOARD, GROUND
EP501 1-537-771-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB304 1-216-295-11 SHORT 0
< IC >
IC100 8-759-100-96 IC NJM4558M-TE2
IC200 8-759-100-96 IC NJM4558M-TE2
IC300 8-759-675-77 IC uDA1350AH
IC301 8-759-675-78 IC uDA1360TS
IC302 8-759-387-77 IC TC7WU04F-TE12L
IC303 8-749-012-70 IC GP1F38R (DIGITAL OPTICAL IN)
IC304 8-759-710-97 IC NJM4565M (TE2)
IC305 8-759-100-96 IC NJM4558M-TE2
IC307 8-759-548-57 IC SN74LV00ANSR
IC400 8-759-633-65 IC M54641L
IC401 8-759-633-65 IC M54641L
IC500 8-759-678-77 IC LA5643
IC501 8-759-604-86 IC M5F7807L
IC502 8-759-656-35 IC NJM7810FA
IC504 8-759-633-42 IC M5293L
IC505 8-759-821-93 IC LA5601
IC506 8-759-592-79 IC BA00AST-V5
IC800 8-759-832-18 IC M30624MGA-A54FP
IC801 8-759-832-19 IC M30803MG-A01FP
< JACK >
J300 1-784-429-11 JACK, PIN 4P (ANALOG IN/OUT)
J302 1-580-394-11 CONNECTOR, DIN 6P (PC LINK)
< COIL >
L100 1-216-295-11 SHORT 0
L200 1-216-295-11 SHORT 0
L300 1-216-295-11 SHORT 0
L301 1-216-295-11 SHORT 0
L302 1-216-295-11 SHORT 0
L303 1-216-295-11 SHORT 0
L304 1-216-295-11 SHORT 0
L306 1-216-295-11 SHORT 0
L307 1-216-295-11 SHORT 0
L308 1-414-235-22 FERRITE 0uH
L309 1-216-295-11 SHORT 0
L310 1-414-235-22 FERRITE 0uH
L315 1-216-295-11 SHORT 0
L321 1-414-235-22 FERRITE 0uH
L341 1-469-407-21 FERRITE 0uH
L342 1-414-235-22 FERRITE 0uH
L401 1-414-234-22 FERRITE 0uH
< TRANSISTOR >
Q100 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO
Q101 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO
Q200 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO
Q201 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO
MAIN
