Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
94
MXD-D40
Q300 8-729-424-08 TRANSISTOR UN2111
Q301 8-729-421-22 TRANSISTOR UN2211
Q302 8-729-424-08 TRANSISTOR UN2111
Q400 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q401 8-729-421-22 TRANSISTOR UN2211
Q500 8-729-230-91 TRANSISTOR 2SC3113-B-TP
Q501 8-729-421-22 TRANSISTOR UN2211
Q502 8-729-421-22 TRANSISTOR UN2211
Q503 8-729-194-57 TRANSISTOR 2SC945-P
Q504 8-729-194-57 TRANSISTOR 2SC945-P
< RESISTOR >
R1 1-216-295-11 SHORT 0 (US, Canadian)
R2 1-216-295-11 SHORT 0 (AEP, UK)
R3 1-216-295-11 SHORT 0 (Singapore)
R100 1-216-073-00 METAL CHIP 10K 5% 1/10W
R101 1-216-025-11 RES-CHIP 100 5% 1/10W
R102 1-216-049-11 RES-CHIP 1K 5% 1/10W
R103 1-216-653-11 METAL CHIP 1.2K 0.5% 1/10W
R104 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R105 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R106 1-216-097-11 RES-CHIP 100K 5% 1/10W
R107 1-216-045-00 METAL CHIP 680 5% 1/10W
R108 1-216-037-00 METAL CHIP 330 5% 1/10W
R109 1-216-049-11 RES-CHIP 1K 5% 1/10W
R110 1-216-017-00 RES-CHIP 47 5% 1/10W
R111 1-216-017-00 RES-CHIP 47 5% 1/10W
R112 1-216-079-00 METAL CHIP 18K 5% 1/10W
R113 1-216-084-00 METAL CHIP 30K 5% 1/10W
R114 1-216-017-00 RES-CHIP 47 5% 1/10W
R115 1-216-105-00 RES-CHIP 220K 5% 1/10W
R116 1-216-049-11 RES-CHIP 1K 5% 1/10W
R200 1-216-073-00 METAL CHIP 10K 5% 1/10W
R201 1-216-025-11 RES-CHIP 100 5% 1/10W
R202 1-216-049-11 RES-CHIP 1K 5% 1/10W
R203 1-216-653-11 METAL CHIP 1.2K 0.5% 1/10W
R204 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R205 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R206 1-216-097-11 RES-CHIP 100K 5% 1/10W
R207 1-216-045-00 METAL CHIP 680 5% 1/10W
R208 1-216-037-00 METAL CHIP 330 5% 1/10W
R209 1-216-049-11 RES-CHIP 1K 5% 1/10W
R210 1-216-017-00 RES-CHIP 47 5% 1/10W
R211 1-216-017-00 RES-CHIP 47 5% 1/10W
R212 1-216-079-00 METAL CHIP 18K 5% 1/10W
R213 1-216-084-00 METAL CHIP 30K 5% 1/10W
R214 1-216-017-00 RES-CHIP 47 5% 1/10W
R215 1-216-105-00 RES-CHIP 220K 5% 1/10W
R216 1-216-049-11 RES-CHIP 1K 5% 1/10W
0R300 1-219-786-11 FUSIBLE 22 5% 1/4W
0R301 1-219-786-11 FUSIBLE 22 5% 1/4W
R302 1-216-101-00 METAL CHIP 150K 5% 1/10W
R303 1-216-025-11 RES-CHIP 100 5% 1/10W
R304 1-216-025-11 RES-CHIP 100 5% 1/10W
R306 1-216-025-11 RES-CHIP 100 5% 1/10W
R312 1-216-025-11 RES-CHIP 100 5% 1/10W
R314 1-216-073-00 METAL CHIP 10K 5% 1/10W
R315 1-216-073-00 METAL CHIP 10K 5% 1/10W
0R317 1-217-637-00 FUSIBLE 1 5% 1/4W
R320 1-216-025-11 RES-CHIP 100 5% 1/10W
R321 1-216-073-00 METAL CHIP 10K 5% 1/10W
R332 1-216-025-11 RES-CHIP 100 5% 1/10W
R333 1-216-025-11 RES-CHIP 100 5% 1/10W
R334 1-216-025-11 RES-CHIP 100 5% 1/10W
R340 1-216-025-11 RES-CHIP 100 5% 1/10W
R341 1-216-025-11 RES-CHIP 100 5% 1/10W
R342 1-216-025-11 RES-CHIP 100 5% 1/10W
R344 1-216-025-11 RES-CHIP 100 5% 1/10W
R345 1-216-295-11 SHORT 0
R346 1-216-025-11 RES-CHIP 100 5% 1/10W
R349 1-216-025-11 RES-CHIP 100 5% 1/10W
R400 1-216-089-11 RES-CHIP 47K 5% 1/10W
R401 1-216-081-00 METAL CHIP 22K 5% 1/10W
R402 1-216-081-00 METAL CHIP 22K 5% 1/10W
R500 1-216-097-11 RES-CHIP 100K 5% 1/10W
R501 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R502 1-216-040-00 RES-CHIP 430 5% 1/10W
R503 1-216-044-00 METAL CHIP 620 5% 1/10W
R504 1-216-089-11 RES-CHIP 47K 5% 1/10W
R505 1-216-073-00 METAL CHIP 10K 5% 1/10W
R506 1-216-025-11 RES-CHIP 100 5% 1/10W
R507 1-216-097-11 RES-CHIP 100K 5% 1/10W
R508 1-216-083-00 METAL CHIP 27K 5% 1/10W
R509 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R510 1-216-073-00 METAL CHIP 10K 5% 1/10W
R513 1-216-049-11 RES-CHIP 1K 5% 1/10W
R514 1-216-049-11 RES-CHIP 1K 5% 1/10W
R516 1-216-033-00 METAL CHIP 220 5% 1/10W
R518 1-216-054-00 RES-CHIP 1.6K 5% 1/10W
R519 1-216-039-00 METAL CHIP 390 5% 1/10W
R520 1-216-054-00 RES-CHIP 1.6K 5% 1/10W
R521 1-216-039-00 METAL CHIP 390 5% 1/10W
R522 1-216-097-11 RES-CHIP 100K 5% 1/10W
R550 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R551 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R800 1-216-073-00 METAL CHIP 10K 5% 1/10W
R801 1-216-073-00 METAL CHIP 10K 5% 1/10W
R802 1-216-073-00 METAL CHIP 10K 5% 1/10W
R806 1-216-073-00 METAL CHIP 10K 5% 1/10W
R807 1-216-073-00 METAL CHIP 10K 5% 1/10W
R809 1-216-097-11 RES-CHIP 100K 5% 1/10W
R810 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R811 1-216-073-00 METAL CHIP 10K 5% 1/10W
R812 1-216-073-00 METAL CHIP 10K 5% 1/10W
R814 1-216-073-00 METAL CHIP 10K 5% 1/10W
R830 1-216-073-00 METAL CHIP 10K 5% 1/10W
R833 1-216-295-11 SHORT 0
R838 1-216-295-11 SHORT 0
R839 1-216-295-11 SHORT 0
R850 1-216-073-00 METAL CHIP 10K 5% 1/10W
R852 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R855 1-216-073-00 METAL CHIP 10K 5% 1/10W
R860 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
R861 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
R870 1-216-025-11 RES-CHIP 100 5% 1/10W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN
