Sony SLV-D360P - Page 104

7-8
OSD PICTURE
MISSING
CHECK IC601-37, 38pin
14.318MHz signal out
CHECK IC601-52,53pin
AFC signal out
CHANGE IC601
CHECK C618,C619
CHECK C626, R639
YES
NO
YES
NO
(VCR Section)
SELECT LINE MODE
WITHOUT INPUT SIGNAL
BLUE MISSING IN
STOP MODE
CHANGE IC601
SHOW WEAK
CHANNEL NO IN CHANNEL
SETUP OF OSP SETUP
CHECK IC601-37, 38pin
14.318MHz out
CHECK IC601-52, 53pin
AFC signal
CHECK C626, R639
CHECK C618, C619
NO
NO
NO
YES
YES
YES
SET THE SHOW WEAK
CHANNELS TO "NO"
CHECK IC601-50pin
SYNK signal
CHECK C622, R638
NO
YES
(VCR Section)
