6-1
SECTION 6
ELECTRICAL ADJUSTMENTS
CIRCUIT BOARDS LOCATION
CP-1 PWB Assembly
VP-1 PWB Assembly
3 in 1 Tuner
(Tuner / RF Conv.)
TM-1 PWB
TM-9 PWB
TM-2 PWB
SLV-E120AE/E220AE/UY/VP1/VP2/E270CP/VC1/VC2/E280CP/UX/VC1/VC2
