8-1
NOTE :
r
Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
r
-XX, -X mean standardized parts, so they may
have some difference from the original one.
r
RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
r
Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
r
SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
r
CAPACITORS
uF : µ F
r
COILS
uH : µ H
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
SECTION 8
ELECTRICAL PARTS LIST
* A-6796-554-A CP-A BOARD, COMPLETE (E280UX)
* A-6796-566-A CP-A BOARD, COMPLETE (E280VC1)
* A-6796-570-A CP-A BOARD, COMPLETE (E280VC2)
* A-6796-572-A CP-A BOARD, COMPLETE (E280CP)
* A-6796-581-A CP-A BOARD, COMPLETE (E270VC1,VC2)
* A-6796-594-A CP-A BOARD, COMPLETE (E220UY)
* A-6796-599-A CP-A BOARD, COMPLETE (E220AE)
* A-6796-560-A CP-A BOARD, COMPLETE (E220VP1)
* A-6796-602-A CP-A BOARD, COMPLETE (E220VP2)
* A-6796-604-A CP-A BOARD, COMPLETE (E120AE)
* A-6796-591-A CP-A BOARD, COMPLETE (E270CP)
*********************
1-533-583-11 HOLDER, FUSE
< CAPACITOR >
C1001 1-126-301-11 ELECT 1uF 20% 50V
C1002 1-111-241-11 ELECT 10uF 20% 16V
C1003 1-126-154-11 ELECT 47uF 20% 6.3V
C1004 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1005 1-126-154-11 ELECT 47uF 20% 6.3V
C1006 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1007 1-126-301-11 ELECT 1uF 20% 50V
C1009 1-109-889-11 ELECT 1uF 20% 50V
C1010 1-164-076-11 CERAMIC 180PF 10% 50V
C1011 1-162-288-31 CERAMIC 330PF 10% 50V
C1012 1-162-209-31 CERAMIC 27PF 5% 50V
C1013 1-124-234-00 ELECT 22uF 20% 16V
C1014 1-102-129-00 CERAMIC 10000PF 10% 50V
C1015 1-162-211-11 CERAMIC 33PF 5% 50V
C1016 1-102-129-00 CERAMIC 10000PF 10% 50V
C1017 1-102-129-00 CERAMIC 10000PF 10% 50V
C1018 1-161-059-00 CERAMIC 0.047uF 10% 50V
C1019 1-126-301-11 ELECT 1uF 20% 50V
C1021 1-161-059-00 CERAMIC 0.047uF 10% 50V
C1022 1-126-301-11 ELECT 1uF 20% 50V
C1023 1-161-059-00 CERAMIC 0.047uF 10% 50V
C1024 1-161-772-11 CERAMIC 0.1uF 10% 25V
C1025 1-102-129-00 CERAMIC 10000PF 10% 50V
C1026 1-126-301-11 ELECT 1uF 20% 50V
C1027 1-161-055-00 CERAMIC 0.022uF 10% 50V
C1028 1-126-301-11 ELECT 1uF 20% 50V
C1029 1-126-154-11 ELECT 47uF 20% 6.3V
C1030 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1031 1-102-129-00 CERAMIC 10000PF 10% 50V
C1032 1-126-301-11 ELECT 1uF 20% 50V
C1033 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C1040 1-111-241-11 ELECT 10uF 20% 16V
C1041 1-162-209-31 CERAMIC 27PF 5% 50V
C1043 1-109-889-11 ELECT 1uF 20% 50V
(E120AE,E220 Series,E280UX)
C1044 1-101-880-11 CERAMIC 47PF 5% 50V
(EXCEPT E270 Series,E280CP,VC1,VC2)
C1046 1-164-086-11 CERAMIC 0.0012uF 20% 50V
C1047 1-101-880-11 CERAMIC 47PF 5% 50V
C1048 1-162-203-31 CERAMIC 15PF 5% 50V
C1050 1-162-203-31 CERAMIC 15PF 5% 50V
C1051 1-101-880-11 CERAMIC 47PF 5% 50V
C1052 1-101-880-11 CERAMIC 47PF 5% 50V
(EXCEPT E270 Series)
C1101 1-126-301-11 ELECT 1uF 20% 50V
C1102 1-126-154-11 ELECT 47uF 20% 6.3V
C1103 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1104 1-102-129-00 CERAMIC 10000PF 10% 50V
C1105 1-102-129-00 CERAMIC 10000PF 10% 50V
C1106 1-102-129-00 CERAMIC 10000PF 10% 50V
C1107 1-102-129-00 CERAMIC 10000PF 10% 50V
C1108 1-161-772-11 CERAMIC 0.1uF 10% 25V
C1109 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1301 1-126-935-11 ELECT 470uF 20% 6.3V
C1302 1-164-159-21 CERAMIC 0.1uF 50V
(E270 Series,E280CP,VC1,VC2)
C1303 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1341 1-109-889-11 ELECT 1uF 20% 50V
(E270 Series,E280CP,VC1,VC2)
C1342 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(E270 Series,E280CP,VC1,VC2)
C1343 1-162-215-11 CERAMIC 47PFF 5% 50V
(EXCEPT E120AE,E220 Series)
C1344 1-109-889-11 ELECT 1uF 20% 50V
(E270Series,E280CP,VC1,VC2)
C1346 1-111-241-11 ELECT 10uF 20% 16V
(EXCEPT E120AE,E220 Series)
C1347 1-111-241-11 ELECT 10uF 20% 16V
(E280UX)
C1350 1-161-021-11 CERAMIC 0.047uF 10% 25V
(E280UX)
C1351 1-111-241-11 ELECT 10uF 20% 16V
(E270 Series,E280CP,VC1,VC2)
C1352 1-126-301-11 ELECT 1uF 20% 50V
(E120AE,E220 Series,E280UX)
CP-A
When indicating parts by reference
number, please include the board.
The CP-A board and CP-1 board
are identical.
SLV-E120AE/E220AE/UY/VP1/VP2/E270CP/VC1/VC2/E280CP/UX/VC1/VC2
