8-11
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MA-400
CN461 1-784-484-11 CONNECTOR, FFC/FPC 5P
(SE610/SE710/SX710/SX717)
CN500 1-793-918-11 CONNECTOR, SQUARE TYPE 21P
(LINE-1 (TV)) (SE610: A, G, K, N)
* CN501 1-568-954-11 PIN, CONNECTOR 5P (SE810/SX810/X9)
CN570 1-793-917-11 CONNECTOR, SQUARE TYPE 21P
(LINE-1 (TV), DECODER/LINE-2 IN)
(SE610: B, E/SE710/SX710/SX717)
CN570 1-793-917-11 CONNECTOR, SQUARE TYPE 21P
(LINE-1 (TV), DECODER/LINE-3 IN)
(SE810/SX810/X9)
CN600 1-778-674-21 CONNECTOR, BOARD TO BOARD 19P
CN601 1-793-673-11 CONNECTOR, BOARD TO BOARD 7P
< DIODE >
D100 8-719-048-26 DIODE GL528V1 (T/S LED)
D110 8-719-200-82 DIODE MPG06D-6052PKG3
D424 8-719-067-40 DIODE STZ6.8N-T146
D500 8-719-071-50 DIODE BZA408B-115
D501 8-719-071-50 DIODE BZA408B-115
D502 8-719-070-59 DIODE PDZ6.8B-115
D503 8-719-977-40 DIODE UDZ-TE-17-13B
D504 8-719-070-59 DIODE PDZ6.8B-115
D570 8-719-071-50 DIODE BZA408B-115
(SE610: B, E/SE710/SE810/
SX710/SX717/SX810/X9)
D571 8-719-070-59 DIODE PDZ6.8B-115
(SE610: B, E/SE710/SE810/
SX710/SX717/SX810/X9)
D572 8-719-977-40 DIODE UDZ-TE-17-13B
(SE610: B, E/SE710/SE810/
SX710/SX717/SX810/X9)
D573 8-719-070-59 DIODE PDZ6.8B-115
D590 8-719-911-19 DIODE 1SS119-25TD
D603 8-719-200-82 DIODE MPG06D-6052PKG3
(SE610: B, E/SE710/SE810/
SX710/SX717/SX810/X9)
D606 8-719-200-82 DIODE MPG06D-6052PKG3
D607 8-719-200-82 DIODE MPG06D-6052PKG3
D702 8-719-982-26 DIODE MTZJ-T-77-33
D720 8-719-911-19 DIODE 1SS119-25TD
D721 8-719-911-19 DIODE 1SS119-25TD
D750 8-719-200-82 DIODE MPG06D-6052PKG3
D800 8-719-911-19 DIODE 1SS119-25TD
(SE710/SE810/SX710/SX717/SX810/X9)
D871 8-719-070-59 DIODE PDZ6.8B-115 (X9)
D872 8-719-070-59 DIODE PDZ6.8B-115 (X9)
D873 8-719-070-59 DIODE PDZ6.8B-115 (X9)
< IC >
IC130 8-759-645-07 IC LB1943N
IC160 8-759-248-87 IC MM1256XF-BE
IC161 8-759-682-41 IC M24C32-WMN6T (A) (X9: B, D, E, G)
IC161 8-759-714-06 IC M24C16-WMN6T (A)
(SE610/SE710/SE810/SX710/
SX717/SX810/X9N)
IC162 8-759-694-68 IC M37970MGA-051GP (SE610)
IC162 8-759-694-69 IC M37970MGA-050GP
(SE710/SE810/SX710/SX717/SX810/X9)
IC201 8-759-699-51 IC LA71710M-MPB-E
IC301 8-759-638-55 IC TDA9605H/N2, 518
IC351 8-759-499-30 IC BA7755AF-E2
IC420 8-759-643-83 IC uPD16315GB-3BS
IC460 8-759-830-96 IC SFH5110-40
0IC601 8-759-438-18 IC PQ12RD08
IC850 8-759-484-61 IC SDA5650X-GEG
(SE710/SE810/SX710/SX717/SX810/X9)
IC970 8-759-438-17 IC LA7337
(SE610B/SE710B/SE810B/SX710B/X9B)
< JACK >
J500 1-784-414-11 JACK, PIN 2P (LINE-2 OUT)
(SE710/SE810/SX710/SX717/SX810/X9)
J871 1-779-013-11 JACK, MINIATURE (STB CONTROL)
(X9: B, D, E, G)
< JUMPER RESISTOR >
JR001 1-216-295-11 SHORT 0
JR003 1-216-295-11 SHORT 0
JR004 1-216-295-11 SHORT 0
JR006 1-216-295-11 SHORT 0
JR007 1-216-295-11 SHORT 0
JR008 1-216-295-11 SHORT 0
JR009 1-216-295-11 SHORT 0
JR010 1-216-295-11 SHORT 0
JR011 1-216-295-11 SHORT 0
JR012 1-216-295-11 SHORT 0
JR013 1-216-295-11 SHORT 0
JR014 1-216-295-11 SHORT 0
JR015 1-216-295-11 SHORT 0
JR016 1-216-295-11 SHORT 0
JR017 1-216-295-11 SHORT 0
JR018 1-216-295-11 SHORT 0
JR019 1-216-295-11 SHORT 0
JR020 1-216-295-11 SHORT 0
JR021 1-216-295-11 SHORT 0
JR022 1-216-295-11 SHORT 0
JR201 1-216-296-11 SHORT 0
JR202 1-216-296-11 SHORT 0
JR203 1-216-296-11 SHORT 0
JR204 1-216-296-11 SHORT 0
JR205 1-216-296-11 SHORT 0
JR206 1-216-296-11 SHORT 0
JR207 1-216-296-11 SHORT 0
JR208 1-216-296-11 SHORT 0
JR209 1-216-296-11 SHORT 0
JR210 1-216-296-11 SHORT 0
JR211 1-216-296-11 SHORT 0
JR212 1-216-296-11 SHORT 0
JR213 1-216-296-11 SHORT 0
JR214 1-216-296-11 SHORT 0
JR215 1-216-296-11 SHORT 0
JR216 1-216-296-11 SHORT 0
JR217 1-216-296-11 SHORT 0
JR219 1-216-296-11 SHORT 0
JR220 1-216-296-11 SHORT 0
JR221 1-216-296-11 SHORT 0
JR222 1-216-296-11 SHORT 0
JR223 1-216-296-11 SHORT 0
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
