8-12
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
JR224 1-216-296-11 SHORT 0
JR225 1-216-296-11 SHORT 0
JR226 1-216-296-11 SHORT 0
JR227 1-216-296-11 SHORT 0
JR228 1-216-296-11 SHORT 0
JR229 1-216-296-11 SHORT 0
JR230 1-216-296-11 SHORT 0
JR231 1-216-296-11 SHORT 0
JR232 1-216-296-11 SHORT 0
JR233 1-216-296-11 SHORT 0
JR234 1-216-296-11 SHORT 0
JR235 1-216-296-11 SHORT 0
JR236 1-216-296-11 SHORT 0
JR238 1-216-296-11 SHORT 0
JR239 1-216-296-11 SHORT 0
JR240 1-216-296-11 SHORT 0
JR241 1-216-296-11 SHORT 0
JR242 1-216-296-11 SHORT 0
JR243 1-216-296-11 SHORT 0
JR244 1-216-296-11 SHORT 0
JR245 1-216-296-11 SHORT 0
JR246 1-216-296-11 SHORT 0
JR247 1-216-296-11 SHORT 0
JR248 1-216-296-11 SHORT 0
JR249 1-216-296-11 SHORT 0
JR251 1-216-296-11 SHORT 0
JR252 1-216-296-11 SHORT 0
JR253 1-216-296-11 SHORT 0
JR254 1-216-296-11 SHORT 0
JR255 1-216-296-11 SHORT 0
JR256 1-216-296-11 SHORT 0
JR257 1-216-296-11 SHORT 0
JR258 1-216-296-11 SHORT 0
JR259 1-216-296-11 SHORT 0
JR260 1-216-295-11 SHORT 0
JR261 1-216-296-11 SHORT 0
JR262 1-216-296-11 SHORT 0
JR263 1-216-295-11 SHORT 0
JR264 1-216-296-11 SHORT 0
JR265 1-216-296-11 SHORT 0
JR266 1-216-296-11 SHORT 0
JS351 1-216-295-11 SHORT 0 (SE810/SX810/X9)
JS591 1-216-295-11 SHORT 0
< COIL >
L140 1-414-936-21 INDUCTOR 22uH
L160 1-414-936-21 INDUCTOR 22uH
L161 1-414-936-21 INDUCTOR 22uH
L201 1-414-934-21 INDUCTOR 10uH
L202 1-414-934-21 INDUCTOR 10uH
L203 1-414-934-21 INDUCTOR 10uH
L204 1-414-934-21 INDUCTOR 10uH
L205 1-414-940-21 INDUCTOR 100uH
L251 1-414-479-11 INDUCTOR 47nH
L252 1-414-479-11 INDUCTOR 47nH
L253 1-414-479-11 INDUCTOR 47nH (SE810/SX810/X9)
L254 1-414-479-11 INDUCTOR 47nH
(SE610: B, E/SE710/SE810/
SX710/SX717/SX810/X9)
L255 1-414-479-11 INDUCTOR 47nH
L281 1-414-940-21 INDUCTOR 100uH
L301 1-414-940-21 INDUCTOR 100uH
L351 1-414-940-21 INDUCTOR 100uH
L352 1-414-940-21 INDUCTOR 100uH
L353 1-216-295-11 SHORT 0
L355 1-216-295-11 SHORT 0
L356 1-216-295-11 SHORT 0
L357 1-216-295-11 SHORT 0
L358 1-216-295-11 SHORT 0
L359 1-216-295-11 SHORT 0
L360 1-216-295-11 SHORT 0
L361 1-216-295-11 SHORT 0
L362 1-216-295-11 SHORT 0
L390 1-410-687-11 INDUCTOR 1.2mH (SE810/SX810/X9)
L460 1-414-938-21 INDUCTOR 47uH
L510 1-414-940-21 INDUCTOR 100uH
L660 1-414-930-21 INDUCTOR 2.2uH
L661 1-414-936-21 INDUCTOR 22uH
(SE610: B, K, N/SE710: B, K, N/SE810: B, K, N/
SX710: B, K, N/X9: B, N)
L662 1-414-936-21 INDUCTOR 22uH
L663 1-414-936-21 INDUCTOR 22uH
L701 1-414-930-21 INDUCTOR 2.2uH
L750 1-414-930-21 INDUCTOR 2.2uH
L751 1-414-934-21 INDUCTOR 10uH
L871 1-414-934-21 INDUCTOR 10uH (X9: B, D, E, G)
L970 1-414-933-21 INDUCTOR 6.8uH
(SE610B/SE710B/SE810B/SX710B/X9B)
L971 1-414-945-21 INDUCTOR 27uH
(SE610B/SE710B/SE810B/SX710B/X9B)
L972 1-414-938-21 INDUCTOR 47uH
(SE610B/SE710B/SE810B/SX710B/X9B)
L973 1-414-938-21 INDUCTOR 47uH
(SE610B/SE710B/SE810B/SX710B/X9B)
L975 1-414-934-21 INDUCTOR 10uH
(SE610B/SE710B/SE810B/SX710B/X9B)
< FLUORESCENT INDICATOR >
ND420 1-518-741-11 TUBE, FLUORESCENT INDICATOR
< PHOTO INTERRUPTER >
PH100 8-749-015-86 PHOTO INTERRUPTER GP3S120S
PH101 8-749-015-86 PHOTO INTERRUPTER GP3S120S
< IC LINK >
0PS120 1-532-605-00 LINK, IC (0.4A)
0PS390 1-532-727-11 LINK, IC (0.25A) (SE810/SX810/X9)
0PS602 1-532-727-11 LINK, IC (0.25A) (SE610: B, E/SE710/SE810/
SX710/SX717/SX810/X9)
< TRANSISTOR >
Q100 8-729-043-84 TRANSISTOR PT380F3
Q101 8-729-043-84 TRANSISTOR PT380F3
Q102 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
MA-400
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
