8-17
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
T390 1-423-415-11 TRANSFORMER, BIAS OSCILLATION
(SE810/SX810/X9)
< TUNER >
TU702 1-693-436-81 TUNER, IF (BTF-3WC428)
(SE610: E, N/SE710 :E, N, I/SE810: E, N/
SX710: E, N/SX717E/X9E)
TU702 1-693-437-81 TUNER, IF (BTF-3WU604)
(SE610G/SE710G/SE810G/X9G)
TU702 1-693-438-81 TUNER, IF (BTF-3WC446)
(SE610B/SE710B/SE810B/SX710B/X9B)
TU702 1-693-439-81 TUNER, IF (BTF-3WC429)
(SE610: A, K/SE710: D, K/SE810: D, K/
SX710: D, K/SX717D/SX810/X9D)
TU703 1-693-521-11 TUNER, IF (BTF-2WC421)
(SE610: E, N/SE710 :E, N, I/SE810: E, N/
SX710: E, N/SX717E/X9E)
< VIBRATOR >
X160 1-579-463-11 VIBRATOR, CRYSTAL (32.768kHz)
X161 1-781-717-21 VIBRATOR, CRYSTAL (17.734475MHz)
X200 1-579-608-21 VIBRATOR, CRYSTAL (4.433619MHz)
* 1-468-458-14 POWER BLOCK (SRV938EK)
***********************
(Ref.No. 2,000 Series)
< CAPACITOR >
0C101 9-885-001-69 METAL 0.1uF
0C102 9-885-001-69 METAL 0.1uF
0C103 9-885-001-70 CERAMIC 1000PF 250V
0C104 9-885-001-70 CERAMIC 1000PF 250V
0C105 9-885-001-70 CERAMIC 1000PF 250V
0C108 1-113-937-91 CERAMIC 2200PF 250V
0C109 1-113-937-91 CERAMIC 2200PF 250V
0C151 9-885-001-81 ELECT 47uF 400V
C153 1-163-015-91 CERAMIC CHIP 3300PF
C155 1-126-965-91 ELECT 22uF 50V
C156 1-126-960-91 ELECT 1uF 50V
C157 1-163-009-91 CERAMIC CHIP 1000PF
C158 1-163-273-91 CERAMIC CHIP 820PF
C159 1-163-251-91 CERAMIC CHIP 100PF
C160 1-163-021-91 CERAMIC CHIP 10000PF
C161 1-163-009-91 CERAMIC CHIP 1000PF
C201 9-885-001-91 ELECT 220uF 25V
C202 1-126-925-91 ELECT 470uF 10V
C203 1-126-934-91 ELECT 220uF 16V
C206 1-126-947-91 ELECT 47uF 35V
C207 1-126-964-91 ELECT 10uF 50V
C208 1-126-925-91 ELECT 470uF 10V
C209 1-163-021-91 CERAMIC 0.01uF 50V
C212 1-163-021-91 CERAMIC 0.01uF 50V
C213 1-126-956-91 ELECT 0.1uF 50V
C251 1-126-967-91 ELECT 47uF 50V
C252 1-111-065-11 ELECT 680uF 25V
C253 1-111-016-91 ELECT 1200uF 10V
C254 9-885-001-92 ELECT 470uF 25V
C261 1-164-489-91 CERAMIC CHIP 0.22uF 16V
C301 1-111-118-91 ELECT 220uF 50V
MA-400 POWER BLOCK
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
C303 1-126-965-91 ELECT 22uF 50V
< CONNECTOR >
0CN101 1-580-230-11 CONNECTOR
CN201 1-778-675-21 CONNECTOR 19P
CN202 1-793-674-21 CONNECTOR 7P
< DIODE >
0D101 9-880-927-01 DIODE 1N4005
0D102 9-880-927-01 DIODE 1N4005
0D103 9-880-927-01 DIODE 1N4005
0D104 9-880-927-01 DIODE 1N4005
D151 8-719-084-75 DIODE P6KE300 ARL
D152 9-885-001-78 DIODE UF4007
D153 9-885-001-79 DIODE 1SS119
D154 9-885-001-80 DIODE PR1003
D158 9-880-991-01 DIODE MA4270
D203 9-885-001-86 DIODE MTZJ5.1
D204 9-885-001-79 DIODE 1SS119
D205 9-885-001-79 DIODE 1SS119
D251 9-885-001-80 DIODE PR1003
D252 9-885-001-87 DIODE UF3DL
D253 9-885-001-88 DIODE SB340L
D254 9-885-001-80 DIODE PR1003
D301 9-885-001-87 DIODE UF3DL
D302 9-885-001-89 DIODE D2S4M
D303 9-885-001-90 DIODE MTZJ20
D304 9-885-001-89 DIODE D2S4M
D307 9-885-001-89 DIODE D2S4M
< FUSE >
0F101 9-885-001-72 FUSE (T2AL/250V)
< IC >
0IC151 9-885-001-74 IC TDA16846
IC251 9-885-001-82 IC AN1431T
< LINE FILTER/COIL >
0L101 9-885-001-67 LINE FILTER 10uH
0L102 9-885-001-68 LINE FILTER 33mH
0L103 9-885-001-68 LINE FILTER 33mH
L201 9-885-001-93 CHOKE COIL 10uH
L202 9-885-001-93 CHOKE COIL 10uH
L205 9-885-001-94 CHOKE COIL 1uH
< PHOTO COUPLER >
0PC151 9-885-001-75 COUPLER, PHOTO ON3171
< IC LINK >
0PS201 1-533-592-21 LINK, IC (1.6A)
0PS202 1-533-593-21 LINK, IC (2A)
0PS251 1-533-589-21 LINK, IC (750mA)
< TRANSISTOR >
0Q151 9-885-001-73 TRANSISTOR 2SK3047
0Q201 8-729-141-01 TRANSISTOR 2SB733
