8-18
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q203 8-729-030-98 TRANSISTOR 2PD601A
Q204 8-729-139-97 TRANSISTOR 2SC2785
Q205 8-729-018-99 TRANSISTOR 2SD2394
Q206 8-729-139-97 TRANSISTOR 2SC2785
Q207 9-885-001-83 TRANSISTOR 2SD1862
Q210 8-729-043-32 TRANSISTOR DTA114EKA
Q211 8-729-043-29 TRANSISTOR DTC114EKA
Q301 8-729-018-99 TRANSISTOR 2SD2394
Q302 9-885-001-84 TRANSISTOR DTC143EKA
Q303 8-729-018-99 TRANSISTOR 2SD2394
Q304 8-729-139-97 TRANSISTOR 2SC2785
Q305 8-729-141-01 TRANSISTOR 2SB733
Q306 9-885-001-84 TRANSISTOR DTC143EKA
Q307 9-885-001-85 TRANSISTOR 2SA1015
< RESISTOR >
R101 9-885-001-71 CARBON 1M 1/2W
R151 1-247-903-91 CARBON 1M 1/4W
R152 1-247-903-91 CARBON 1M 1/4W
R155 1-216-073-21 RES, CHIP 10K 1/10W
R156 1-259-880-91 CARBON 2.2M 1/4W
R157 1-259-880-91 CARBON 2.2M 1/4W
R158 1-247-805-91 CARBON 82 1/4W
R159 1-249-397-11 CARBON 22 1/4WF
R160 1-247-795-91 CARBON 33 1/4W
R161 1-216-085-21 RES, CHIP 33K 1/10W
R162 1-216-085-21 RES, CHIP 33K 1/10W
R163 1-216-063-21 RES, CHIP 3.9K 1/10W
R164 1-247-861-91 CARBON 18K 1/4W
R201 1-216-049-21 RES, CHIP 1K 1/10W
R203 1-216-452-21 METAL 180 2W
R206 1-216-053-21 RES, CHIP 1.5K 1/10W
R207 1-247-615-91 CARBON 220 1/4W
R208 1-247-615-91 CARBON 220 1/4W
R209 1-247-615-91 CARBON 220 1/4W
R210 1-216-049-21 RES, CHIP 1K 1/10W
R213 1-216-089-21 RES, CHIP 47K 1/10W
R216 1-216-065-21 RES, CHIP 4.7K 1/10W
R217 1-215-857-81 METAL 10 1W
R218 1-215-908-81 METAL 33 3W
R219 1-247-847-91 CARBON 4.7K 1/4W
R220 1-216-065-21 RES, CHIP 4.7K 1/10W
R222 1-247-615-91 CARBON 220 1/4W
R251 1-249-402-11 CARBON 56 1/4W F
R261 1-216-049-21 RES, CHIP 1K 1/10W
R263 1-216-079-21 RES, CHIP 18K 1/10W
R264 1-216-077-21 RES, CHIP 15K 1/10W
R265 1-216-073-21 RES, CHIP 10K 1/10W
R266 1-216-061-21 RES, CHIP 3.3K 1/10W
R301 1-216-073-21 RES, CHIP 10K 1/10W
R302 1-215-869-81 METAL 1K 1W
R306 1-216-073-21 RES, CHIP 10K 1/10W
R307 1-215-869-81 METAL 1K 1W
R308 1-216-049-21 RES, CHIP 1K 1/10W
R311 1-247-885-91 CARBON 10K 1/4W
R312 1-215-880-81 METAL 10 2W
R313 1-215-880-81 METAL 10 2W
R314 1-215-892-81 METAL 1K 2W
R315 1-215-892-81 METAL 1K 2W
R316 1-247-879-91 CARBON 100K 1/4W
< TRANSFORMER >
0T151 9-885-001-76 TRANSFORMER, POWER
< VARIABLE RESISTOR >
VR251 1-241-629-11 VARIABLE RESISTOR 5K
< VARISTOR >
0Z101 9-880-928-01 VARISTOR ERZV10D751
MISCELLANEOUS
**************
4 1-757-593-11 CABLE, FLAT (FDS-10)
(SE610/SE710/SX710/SX717)
4 1-757-594-11 CABLE, FLAT (FDS-9) (SE810/SX810/X9)
5 1-762-844-31 SWITCH, ROTARY (SE810/SX810/X9)
53 1-757-537-11 CABLE, FLAT (FAC-9)
54 1-792-022-11 CABLE, FLAT (FFM-001)
055 1-782-012-11 CORD, POWER
704 1-500-471-11 HEAD, FE
721 A-6775-791-A ACE BLOCK ASSY (ALPS) (EURO 3)
770 1-772-364-11 DRUM ASSY, DZH-0B5A-R (EXCEPT SE610B/
SE710B/SE810B/SX710B/X9B)
770 1-772-365-11 DRUM ASSY, DZH-0B6A-R
(SE610B/SE710B/SE810B/SX710B/X9B)
M902 1-698-971-11 MOTOR, DC (CAPSTAN)
M903 X-3947-577-1 MOTOR ASSY, CAM
**************
HARDWARE LIST
**************
#1 7-685-648-79 SCREW +BVTP 3X12 TYPE2
#3 7-685-646-79 SCREW +BVTP 3X8 TYPE2
#4 7-682-147-01 SCREW +P 3X6
#5 7-685-133-19 SCREW (DIA. 2.6) (IT3B)
ACCESSORIES & PACKING MATERIALS
********************************
1-418-010-11 COMMANDER, STANDARD (RMT-V259)
(SX717/SX810)
1-418-010-31 COMMANDER, STANDARD (RMT-V259B)
(X9N)
1-418-780-11 COMMANDER, STANDARD (RMT-V288)
(SX710: D, E, K, N)
1-418-780-21 COMMANDER, STANDARD (RMT-V288A)
(SX710B)
1-418-782-11 COMMANDER, STANDARD (RMT-V259K)
(SE810: D, E, G, K, N)
1-418-782-21 COMMANDER, STANDARD (RMT-V259L)
(SE810B)
1-476-070-11 CONTROLLER, STB/SAT (RMT-CM103)
(X9: B, D, E)
1-476-070-21 CONTROLLER, STB/SAT (RMT-CM103) (X9G)
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
