Sony STR-DB798 Service Manual

55
STR-DB798
IC201 TC9273N-014
– VIDEO-AU Board –
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
VSS
S1
S2
S3
S4
S5
S6
S7
S8
S9
S10
S11
S1
S2
S3
S4
S5
S6
S7
S8
S9
S10
S11
GND
CK
VDD
STB
DATA
10BIT
LATCH
CIRCUIT
(R-CH)
10BIT
LATCH
CIRCUIT
(L-CH)
LEVEL SHIFT & SHIFT REGISTER
IC301 NJM2595D
15 VOUT2
16 V+
14 SW1
75Ω
DRIVER
6dB
AMP
75Ω
DRIVER
6dB
AMP
11 VOUT3
75Ω
DRIVER
6dB
AMP
13 VIN1
12 GND
10 SW2
9VIN2
3VIN5
4SW3
5VIN4
6SW4
7VIN3
2SW5
1VOUT1
8V–
– VIDEO Board –

Sony STR-DB798 Specifications

General

Impedance	8 Ω
Supported radio bands	FM
Radio Data System (RDS)	Yes
Channels quantity	7 channels
I/O ports	Output(Component x 1, Optical Digital x 1, Composite x 1, S-Video x 1), Input(Component x 2, Optical Digital x 4, S-Video x 4, Coaxial Digital x 2, Composite x 4)
