STR-DB798
8
3-3. COMP-V BOARD
3-4. BACK PANEL BLOCK
3
two connectors
(CN919, 3801)
2
feeder fixed screw
5
connector
(CN3052)
6
COMP-V board
3
connector
(CN168)
1
two screws
(BVTP3
×
8)
4
1
wire (flat type)
(15 core) (CN1103)
2
two connectors
(CN901, 902)
(AEP, Taiwan)
7
back panel block
4
screw
(BV3
×
8 CU)
4
five screws
(BV3
×
8 CU)
3
eight screw
s
(BVTP3
×
8
)
3
eight screws
(BVTP3
×
8)
3
seven screws
(BVTP3
×
8)
5
five screws
(BVTP3
×
10)
6
two screws
(BVTP4
×
8)
