Sony STR-DB798 Service Manual

6
STR-DB798
SECTION 2
GENERAL
This section is extracted from
instruction manual.
Receiver
A.F.D. qj
Cover ws
DIRECT qs
DISPLAY 9
Display 7
INPUT MODE q;
INPUT SELECTOR qf
IR (receptor) 1
MAIN MENU 4
MASTER VOLUME –/+ qa
MEMORY/ENTER 5
MENU 3
MOVIE qh
MULTI CHANNEL DECODING
(indicator) 8
MULTI CH IN qd
MUSIC qg
PHONES (jack) wg
PRESET TUNING –/+ wa
PUSH wf
SPEAKERS (OFF/A/B/A+B) wh
SURR BACK DECODING ql
TUNING –/+ w;
VIDEO 3 INPUT (jacks) wd
2CH qk
–/+ 6
?/1 (power) 2
ALPHABETICAL ORDER
A - L
M - Z
NUMBERS AND SYMBOLS
PU
S
H
263
0
8745
9
1
wawfwgwh
wd
ws
w;
qk qj qh qg qf qd qsql
qa
To remove the cover
Press PUSH to remove the cover. When you remove the
cover, keep the cover out of reach of the children.

Sony STR-DB798 Specifications

General

Impedance	8 Ω
Supported radio bands	FM
Radio Data System (RDS)	Yes
Channels quantity	7 channels
I/O ports	Output(Component x 1, Optical Digital x 1, Composite x 1, S-Video x 1), Input(Component x 2, Optical Digital x 4, S-Video x 4, Coaxial Digital x 2, Composite x 4)
