STR-DB798
9
3-5. DIGITAL BOARD, A/V SYNC BOARD
3
wire
(flat type)
(31 core)
(CN1105)
6
connector
(CNS551)
5
screw
(BVTP3
×
8)
2
7
DIGITAL board
9
A/V SYNC boar
d
8
A/V SYNC holder
1
two connectors
(CN402, 403)
4
three connectors
(CN107, 1110, 1112)
qj
two connectors
(CN412, 413)
3
screw
(PSW3
×
8)
1
connector
(CN178)
qd
connector
(CN408)
q;
connector
(CN301)
7
connector
(CN202)
8
connector
(CN201)
qs
connector
(CN853)
qf
S-VIDEO board
qa
VIDEO board
9
VIDEO-AU board
6
AU-IN board
qk
SPK-B board
qh
SPK-A board
2
STAY-5 board
4
lead wire
qg
two connectors
(CN448, 449)
5
two connectors
(CN102, 103)
3-6. STAY-5/AU-IN/VIDEO-AU/VIDEO/S-VIDEO/SPK-A/SPK-B BOARD
