Sony STR-DB798 Service Manual

76
STR-DB798
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• CAPACITORS
uF: µF
• COILS
uH: µH
• Abbreviation
TW : Taiwan model
4-8 OHM
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
4-8 OHM BOARD (AEP, TW)
**************
< CONNECTOR >
* CN901 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
CN902 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< SWITCH >
S901 1-571-309-31 SWITCH (IMPEDANCE SELECTOR)
************************************************************
A-1112-123-A A CLASS BOARD, COMPLETE
************************
< CAPACITOR >
C2001 1-137-505-11 FILM 220PF 5% 100V
C2002 1-112-103-11 ELECT 47uF 20% 63V
C2004 1-112-122-11 ELECT 220uF 20% 16V
C2005 1-112-131-11 ELECT 330uF 20% 25V
C2006 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2007 1-102-233-00 CERAMIC 33PF 10% 500V
C2008 1-137-383-91 MYLAR 220PF 5% 100V
C2009 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2010 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2011 1-137-503-11 FILM 100PF 5% 100V
C2101 1-137-505-11 FILM 220PF 5% 100V
C2102 1-112-103-11 ELECT 47uF 20% 63V
C2104 1-112-122-11 ELECT 220uF 20% 16V
C2105 1-112-131-11 ELECT 330uF 20% 25V
C2106 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2107 1-102-233-00 CERAMIC 33PF 10% 500V
C2108 1-137-383-91 MYLAR 220PF 5% 100V
C2109 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2110 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2111 1-137-503-11 FILM 100PF 5% 100V
C2201 1-137-505-11 FILM 220PF 5% 100V
C2202 1-112-103-11 ELECT 47uF 20% 63V
C2204 1-112-122-11 ELECT 220uF 20% 16V
C2205 1-112-131-11 ELECT 330uF 20% 25V
C2206 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2207 1-102-233-00 CERAMIC 33PF 10% 500V
C2208 1-137-383-91 MYLAR 220PF 5% 100V
C2209 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2210 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2211 1-137-503-11 FILM 100PF 5% 100V
C2301 1-137-505-11 FILM 220PF 5% 100V
C2302 1-112-103-11 ELECT 47uF 20% 63V
C2304 1-112-122-11 ELECT 220uF 20% 16V
C2305 1-112-131-11 ELECT 330uF 20% 25V
C2306 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2307 1-102-233-00 CERAMIC 33PF 10% 500V
C2308 1-137-383-91 MYLAR 220PF 5% 100V
C2309 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2310 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2311 1-137-503-11 FILM 100PF 5% 100V
C2401 1-137-505-11 FILM 220PF 5% 100V
C2402 1-112-103-11 ELECT 47uF 20% 63V
C2404 1-112-122-11 ELECT 220uF 20% 16V
C2405 1-112-131-11 ELECT 330uF 20% 25V
C2406 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2407 1-102-233-00 CERAMIC 33PF 10% 500V
C2408 1-137-383-91 MYLAR 220PF 5% 100V
C2409 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2410 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2411 1-137-503-11 FILM 100PF 5% 100V
C2501 1-137-505-11 FILM 220PF 5% 100V
C2502 1-112-103-11 ELECT 47uF 20% 63V
C2504 1-112-122-11 ELECT 220uF 20% 16V
C2505 1-112-131-11 ELECT 330uF 20% 25V
C2506 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2507 1-102-233-00 CERAMIC 33PF 10% 500V
C2508 1-137-383-91 MYLAR 220PF 5% 100V
C2509 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2510 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2511 1-137-503-11 FILM 100PF 5% 100V
C2601 1-112-110-11 ELECT 47uF 20% 100V
C2602 1-112-110-11 ELECT 47uF 20% 100V
C2603 1-112-150-11 ELECT 4.7uF 20% 100V
C2605 1-112-151-11 ELECT 22uF 20% 100V
C2606 1-112-151-11 ELECT 22uF 20% 100V
C2701 1-137-505-11 FILM 220PF 5% 100V
C2702 1-112-103-11 ELECT 47uF 20% 63V
C2704 1-112-122-11 ELECT 220uF 20% 16V
C2705 1-112-131-11 ELECT 330uF 20% 25V
C2706 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2707 1-102-233-00 CERAMIC 33PF 10% 500V
C2708 1-137-383-91 MYLAR 220PF 5% 100V
A CLASS

Sony STR-DB798 Specifications

General

Impedance	8 Ω
Supported radio bands	FM
Radio Data System (RDS)	Yes
Channels quantity	7 channels
I/O ports	Output(Component x 1, Optical Digital x 1, Composite x 1, S-Video x 1), Input(Component x 2, Optical Digital x 4, S-Video x 4, Coaxial Digital x 2, Composite x 4)
