STR-DB798
Pin No.
Pin Name
I/O
Description
44
VSS
-
Ground terminal
45
NC
-
Not used
46
DAB_SEL
O
DAB selection signal output terminal Not used
47
RDS.DATA
I
RDS serial data input from the tuner unit (AEP and UK models only)
48
TUNER ST
I
FM stereo detection signal input from the tuner unit
49
TUNER TUNED
I
Tuned detection signal input from the tuner unit
50
TUNER MUTE
O
Muting request control signal output to the tuner unit
51
NC
-
Not used
52 to 54
MD2 to MD0
-
Not used
55
RSTX
I
System reset signal input from the reset signal generator "L": reset
For several hundreds msec. after the power supply rises, "L" is input, then it changes to "H"
56
VCC
-
Power supply terminal (+3.3V)
57
X1
O
System clock output terminal (16.5 MHz)
58
X0
I
System clock input terminal (16.5 MHz)
59
VSS
-
Ground terminal
60
STOP
I
AC off detection signal input terminal
61
RDS_ CLK
I
RDS interrupt clock signal input from the tuner unit (AEP and UK models only)
62
POWER.ON/OFF
I
Power key input terminal "L": power on
63
SIRCS
I
Sircs signal input terminal
64
NC
-
Not used
65
TUNER DO
I
Serial data input from the tuner unit
66
TUNER LATCH
O
Serial data latch pulse signal output to the tuner unit
67
DIR ERROR
I
PLL lock error signal and data error flag input from the digital audio interface receiver
68
VCC
-
Power supply terminal (+3.3V)
69, 70
OPT SEL2,
OPT SEL1
O
Digital input selection signal output terminal
71
XSTATE
I
Source clock selection monitor input from the digital audio interface receiver
72
DATA0
I
Audio serial data input from the digital audio interface receiver
73
XMODE
O
System reset signal output to the digital audio interface receiver "L": reset
74
CKSEL1
O
Output clock selection signal output to the digital audio interface receiver
75
CLK
O
Clock signal output to the digital audio interface receiver
76
CE
O
Chip enable signal output to the digital audio interface receiver
77
VCC
-
Power supply terminal (+3.3V)
78
AUDY_DATA
O
Serial data output to the lip sync adjust
79
DI
O
Write data output to the digital audio interface receiver
80
DO
I
Read data input from the digital audio interface receiver
81
AUDY_CLK
O
Serial data transfer clock signal output to the lip sync adjust
82
LRCK SW
O
Signal selection signal output terminal "L": boot strap signal, "H": L/R sampling clock signal
83
NC
-
Not used
84
GP12
O
Write signal output to the audio digital signal processor
85
DSP_BST
O
Boot strap signal output to the audio digital signal processor
86
XRST
O
System reset signal output to the audio digital signal processor "L": reset
87
PM1
O
PLL initialize signal output to the audio digital signal processor
88
DSP GP9
I
Read ready signal input from the audio digital signal processor
89
DSP_HCS
O
Chip select signal output to the audio digital signal processor
90
DSP_HACN
I
Acknowledge signal input from the audio digital signal processor
91
ADC:RST
O
System reset signal output to the A/D converter "L": reset
92
DAC_RST
O
System reset signal output to the D/A converter "L": reset
