Sony STR-DB798 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
79
STR-DB798
R2003 1-216-809-11 METAL CHIP 100 5% 1/10W
R2004 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2005 1-216-809-11 METAL CHIP 100 5% 1/10W
R2006 1-216-809-11 METAL CHIP 100 5% 1/10W
R2007 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2011 1-216-809-11 METAL CHIP 100 5% 1/10W
R2012 1-216-809-11 METAL CHIP 100 5% 1/10W
R2013 1-216-809-11 METAL CHIP 100 5% 1/10W
R2014 1-216-809-11 METAL CHIP 100 5% 1/10W
R2021 1-216-809-11 METAL CHIP 100 5% 1/10W
R2022 1-216-809-11 METAL CHIP 100 5% 1/10W
R2023 1-216-809-11 METAL CHIP 100 5% 1/10W
R2024 1-216-809-11 METAL CHIP 100 5% 1/10W
R2025 1-216-809-11 METAL CHIP 100 5% 1/10W
R2026 1-216-809-11 METAL CHIP 100 5% 1/10W
R2027 1-216-809-11 METAL CHIP 100 5% 1/10W
R2028 1-216-809-11 METAL CHIP 100 5% 1/10W
R2031 1-216-809-11 METAL CHIP 100 5% 1/10W
R2032 1-216-809-11 METAL CHIP 100 5% 1/10W
R2033 1-216-809-11 METAL CHIP 100 5% 1/10W
R2034 1-216-809-11 METAL CHIP 100 5% 1/10W
R2035 1-216-809-11 METAL CHIP 100 5% 1/10W
R2036 1-216-809-11 METAL CHIP 100 5% 1/10W
R2037 1-216-809-11 METAL CHIP 100 5% 1/10W
R2038 1-216-809-11 METAL CHIP 100 5% 1/10W
R2041 1-216-864-11 SHORT CHIP 0
R2042 1-216-864-11 SHORT CHIP 0
R2043 1-216-864-11 SHORT CHIP 0
R2044 1-216-864-11 SHORT CHIP 0
R2045 1-216-864-11 SHORT CHIP 0
R2046 1-216-864-11 SHORT CHIP 0
R2047 1-216-864-11 SHORT CHIP 0
R2048 1-216-864-11 SHORT CHIP 0
R2049 1-216-864-11 SHORT CHIP 0
R2050 1-216-864-11 SHORT CHIP 0
R2051 1-216-864-11 SHORT CHIP 0
R2052 1-216-864-11 SHORT CHIP 0
R2053 1-216-864-11 SHORT CHIP 0
R2054 1-216-864-11 SHORT CHIP 0
R2055 1-216-864-11 SHORT CHIP 0
R2056 1-216-864-11 SHORT CHIP 0
************************************************************
AC BOARD
*********
1-533-399-31 FUSE HOLDER
< CAPACITOR >
C51 1-112-125-11 ELECT 2200uF 20% 16V
C52 1-136-287-11 FILM 0.0047uF 5% 100V
C53 1-137-465-11 MYLAR 0.056uF 5% 100V
C54 1-112-125-11 ELECT 2200uF 20% 16V
C55 1-126-960-11 ELECT 1uF 20% 50V
C56 1-128-817-11 CERAMIC 470PF 5% 50V
< CONNECTOR >
* CN1 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
CN51 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
D51 8-719-991-33 DIODE 1SS133T-77
D52 8-719-991-33 DIODE 1SS133T-77
D53 8-719-991-33 DIODE 1SS133T-77
D54 8-719-210-21 DIODE 11EQS04
D55 8-719-210-21 DIODE 11EQS04
D56 8-719-210-21 DIODE 11EQS04
D57 8-719-210-21 DIODE 11EQS04
D58 6-500-522-11 DIODE 10EDB40-TA2B5
< JACK >
0J50 1-816-148-11 INLET, AC (-AC IN)
< TRANSISTOR >
Q51 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q52 8-729-201-53 TRANSISTOR 2SA1015-GR
Q53 8-729-029-86 TRANSISTOR DTC124ESA
Q54 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
0R2 1-249-393-11 CARBON 10 5% 1/4W F
R51 1-249-421-11 CARBON 2.2K 5% 1/4W
R52 1-249-429-11 CARBON 10K 5% 1/4W
R53 1-249-415-11 CARBON 680 5% 1/4W
R54 1-249-437-11 CARBON 47K 5% 1/4W
R55 1-249-435-11 CARBON 33K 5% 1/4W
R56 1-249-429-11 CARBON 10K 5% 1/4W
R57 1-249-429-11 CARBON 10K 5% 1/4W
R58 1-247-807-31 CARBON 100 5% 1/4W
< RELAY >
0RY1 1-755-541-11 RELAY
< TRANSFORMER >
0T2 1-437-311-11 TRANSFORMER, POWER (TW)
0T2 1-437-313-11 TRANSFORMER, POWER (AEP, UK)
************************************************************
A-1112-087-A AU-IN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-128-809-11 CERAMIC 100p 5% 50V
C102 1-128-809-11 CERAMIC 100p 5% 50V
C103 1-128-809-11 CERAMIC 100p 5% 50V
C104 1-128-809-11 CERAMIC 100p 5% 50V
C105 1-128-809-11 CERAMIC 100p 5% 50V
C106 1-128-809-11 CERAMIC 100p 5% 50V
C107 1-128-825-11 CERAMIC 2200PF 5% 50V
C110 1-112-090-11 ELECT 100uF 20% 25V
C111 1-112-090-11 ELECT 100uF 20% 25V
C112 1-112-090-11 ELECT 100uF 20% 25V
C113 1-112-090-11 ELECT 100uF 20% 25V
C114 1-112-090-11 ELECT 100uF 20% 25V
C115 1-112-090-11 ELECT 100uF 20% 25V
C120 1-127-876-11 CERAMIC 0.01uF 10% 50V
AU-INACA/V SYNC

Sony STR-DB798 Specifications

General

Impedance	8 Ω
Supported radio bands	FM
Radio Data System (RDS)	Yes
Channels quantity	7 channels
I/O ports	Output(Component x 1, Optical Digital x 1, Composite x 1, S-Video x 1), Input(Component x 2, Optical Digital x 4, S-Video x 4, Coaxial Digital x 2, Composite x 4)
