Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
87
STR-DB798
R1652 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1653 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1654 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1655 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1656 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1657 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1658 1-216-809-11 METAL CHIP 100 5% 1/10W
R1659 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1660 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1661 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1662 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1663 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1664 1-216-809-11 METAL CHIP 100 5% 1/10W
R1665 1-216-809-11 METAL CHIP 100 5% 1/10W
R1666 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1667 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1669 1-216-809-11 METAL CHIP 100 5% 1/10W
R1670 1-216-809-11 METAL CHIP 100 5% 1/10W
R1671 1-216-809-11 METAL CHIP 100 5% 1/10W
R1673 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1674 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1675 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1676 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1677 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1678 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1679 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1680 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1681 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1682 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1683 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1684 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1685 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1687 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1690 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1691 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1692 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1693 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1694 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1695 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1696 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1697 1-216-833-11 METAL CHIP 10K 5% 1/10W
(TW)
R1697 1-216-864-11 SHORT CHIP 0 (AEP, UK)
R1698 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1699 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1701 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1702 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1703 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1704 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1705 1-216-809-11 METAL CHIP 100 5% 1/10W
(AEP, UK)
R1710 1-216-809-11 METAL CHIP 100 5% 1/10W
(AEP, UK)
R1711 1-216-809-11 METAL CHIP 100 5% 1/10W
(AEP, UK)
R1712 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1713 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1714 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1715 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1716 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1717 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1718 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1719 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1720 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1722 1-216-864-11 SHORT CHIP 0
R1724 1-216-864-11 SHORT CHIP 0
R1957 1-216-819-11 METAL CHIP 680 5% 1/10W
R1958 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X1101 1-781-465-21 VIBRATOR, CRYSTAL (12.288MHz)
X1201 1-813-284-21 QUARTZ CRYSTAL (13.9MHz)
X1601 1-795-179-21 VIBRATOR, CERAMIC (16.5MHz)
************************************************************
DIRECT BOARD
************
< CONNECTOR >
CN1062 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< RESISTOR >
R1057 1-247-863-11 CARBON 22K 5% 1/4W
R1060 1-249-437-11 CARBON 47K 5% 1/4W
< SWITCH >
S1061 1-762-875-21 SWITCH, KEYBOARD (DIRECT)
S1062 1-762-875-21 SWITCH, KEYBOARD (MULTI CH IN)
************************************************************
1-867-412-11 DISPLAY BOARD
*************
4-245-442-01 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C1001 1-128-809-11 CERAMIC 100PF 5% 50V
C1002 1-128-809-11 CERAMIC 100PF 5% 50V
C1003 1-128-825-11 CERAMIC 2200PF 5% 50V
C1005 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1006 1-128-809-11 CERAMIC 100PF 5% 50V
C1007 1-128-813-11 CERAMIC 220PF 5% 50V
C1008 1-128-813-11 CERAMIC 220PF 5% 50V
C1009 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1010 1-124-635-00 ELECT 220uF 20% 6.3V
C1011 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1012 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1013 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1014 1-126-796-11 ELECT 22uF 20% 50V
C1015 1-128-813-11 CERAMIC 220PF 5% 50V
C1016 1-128-813-11 CERAMIC 220PF 5% 50V
C1017 1-128-813-11 CERAMIC 220PF 5% 50V
C1018 1-128-813-11 CERAMIC 220PF 5% 50V
C1019 1-128-813-11 CERAMIC 220PF 5% 50V
C1020 1-128-813-11 CERAMIC 220PF 5% 50V
C1021 1-128-813-11 CERAMIC 220PF 5% 50V
DIGITAL DIRECT DISPLAY
