Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 46 —
< FLUORESCENT TUBE >
FL101 1-517-770-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC100 8-759-577-79 IC uPD780208GF-032-3BA
(EXCEPT DE535:US,CND)
IC100 8-759-577-91 IC M62438FP-600D (DE535:US,CND)
IC101 8-759-332-18 IC GP1U27XB
IC102 8-759-962-08 IC BA6208
IC1001 8-759-545-07 IC TMP87C447U-4A06 (DE535/V525)
IC1002 8-759-916-12 IC SN74HC00AN (DE535/V525)
< COIL >
L101 1-410-509-11 INDUCTOR 10uH
L1001 1-408-080-00 INDUCTOR 100uH (DE535/V525)
< TRANSISTOR >
Q101 8-729-900-36 TRANSISTOR DTC124ES
Q102 8-729-900-63 TRANSISTOR DTA124ES
Q115 8-729-900-36 TRANSISTOR DTC124ES
Q116 8-729-900-36 TRANSISTOR DTC124ES
Q1001 8-729-119-78 TRANSISTOR 2SC403SP-51 (DE535/V525)
Q1002 8-729-119-78 TRANSISTOR 2SC403SP-51 (DE535/V525)
Q1004 8-729-801-93 TRANSISTOR 2SD1387 (DE535/V525)
Q1005 8-729-801-93 TRANSISTOR 2SD1387 (DE535/V525)
< RESISTOR >
R020 1-249-421-11 CARBON 2.2K 5% 1/4W F
R021 1-249-421-11 CARBON 2.2K 5% 1/4W F
R022 1-249-433-11 CARBON 22K 5% 1/4W
R023 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT AEP,EE,CIS/SE491)
R024 1-249-433-11 CARBON 22K 5% 1/4W
(DE435,V424,SE491)
R025 1-249-433-11 CARBON 22K 5% 1/4W
R026 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT AEP,EE,CIS)
R027 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT AEP,EE,CIS)
R028 1-249-433-11 CARBON 22K 5% 1/4W
R029 1-249-433-11 CARBON 22K 5% 1/4W
R030 1-249-433-11 CARBON 22K 5% 1/4W
! R099 1-249-383-11 CARBON 1.5 5% 1/6W F
(EXCEPT US,CND)
! R099 1-249-387-81 CARBON 3.3 5% 1/4W F
(US,CND)
! R100 1-249-383-11 CARBON 1.5 5% 1/6W F
(EXCEPT US,CND)
! R100 1-249-387-81 CARBON 3.3 5% 1/4W F
(US,CND)
R101 1-247-807-31 CARBON 100 5% 1/4W
R102 1-249-417-11 CARBON 1K 5% 1/4W F
R103 1-247-807-31 CARBON 100 5% 1/4W
R104 1-247-807-31 CARBON 100 5% 1/4W
R105 1-249-425-11 CARBON 4.7K 5% 1/4W F
R106 1-247-807-31 CARBON 100 5% 1/4W
R107 1-247-807-31 CARBON 100 5% 1/4W
R108 1-247-807-31 CARBON 100 5% 1/4W
R109 1-247-807-31 CARBON 100 5% 1/4W
R110 1-247-807-31 CARBON 100 5% 1/4W
R111 1-247-807-31 CARBON 100 5% 1/4W
R112 1-247-807-31 CARBON 100 5% 1/4W
R113 1-247-807-31 CARBON 100 5% 1/4W
R114 1-247-807-31 CARBON 100 5% 1/4W
R115 1-247-807-31 CARBON 100 5% 1/4W
R116 1-247-807-31 CARBON 100 5% 1/4W
R117 1-247-807-31 CARBON 100 5% 1/4W
R118 1-247-807-31 CARBON 100 5% 1/4W
R119 1-247-807-31 CARBON 100 5% 1/4W
R120 1-247-807-31 CARBON 100 5% 1/4W
R121 1-247-807-31 CARBON 100 5% 1/4W
R122 1-247-807-31 CARBON 100 5% 1/4W
R123 1-249-429-11 CARBON 10K 5% 1/4W
R124 1-249-433-11 CARBON 22K 5% 1/4W
(DE435:AEP,AUS)
R124 1-249-435-11 CARBON 33K 5% 1/4W
(EE,CIS)
R124 1-249-427-11 CARBON 6.8K 5% 1/4W F
(DE435:MY,SP/V424/DE535:AU)
R124 1-247-843-11 CARBON 3.3K 5% 1/4W
(V525/SE491)
R124 1-249-431-11 CARBON 15K 5% 1/4W
(DE535:US,CND)
R124 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE535:E)
R124 1-249-429-11 CARBON 10K 5% 1/4W
(DE535:MY,SP)
R125 1-249-421-11 CARBON 2.2K 5% 1/4W F
(AEP)
R125 1-249-427-11 CARBON 6.8K 5% 1/4W F
(DE535:E EE,CIS/SE491)
R125 1-247-843-11 CARBON 3.3K 5% 1/4W
(DE435:MY,SP DE535:MY,SP/V424)
R125 1-249-433-11 CARBON 22K 5% 1/4W
(DE435:AUS)
R125 1-249-415-11 CARBON 680 5% 1/4W F
(DE535:US,CND)
R125 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE535:AUS)
R125 1-249-429-11 CARBON 10K 5% 1/4W
(V525)
R126 1-249-427-11 CARBON 6.8K 5% 1/4W F
R127 1-249-427-11 CARBON 6.8K 5% 1/4W F
R128 1-249-427-11 CARBON 6.8K 5% 1/4W F
R129 1-249-427-11 CARBON 6.8K 5% 1/4W F
R130 1-249-429-11 CARBON 10K 5% 1/4W
(DE435/SE491/V424)
R131 1-249-425-11 CARBON 4.7K 5% 1/4W F
R132 1-249-425-11 CARBON 4.7K 5% 1/4W F
R133 1-249-425-11 CARBON 4.7K 5% 1/4W F
R134 1-249-425-11 CARBON 4.7K 5% 1/4W F
R135 1-249-425-11 CARBON 4.7K 5% 1/4W F
R136 1-249-433-11 CARBON 22K 5% 1/4W
R137 1-249-441-11 CARBON 100K 5% 1/4W
R138 1-249-417-11 CARBON 1K 5% 1/4W F
