Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 47 —
R140 1-249-411-11 CARBON 330 5% 1/4W
R151 1-249-441-11 CARBON 100K 5% 1/4W
R169 1-249-433-11 CARBON 22K 5% 1/4W
R181 1-249-412-11 CARBON 390 5% 1/4W F
R182 1-249-412-11 CARBON 390 5% 1/4W F
R183 1-249-412-11 CARBON 390 5% 1/4W F
R184 1-249-412-11 CARBON 390 5% 1/4W F
R1001 1-249-429-11 CARBON 10K 5% 1/4W
(DE535/SE491/V525)
R1002 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE535/V525)
R1003 1-249-429-11 CARBON 10K 5% 1/4W
(DE535/SE491/V525)
R1004 1-249-393-11 CARBON 10 5% 1/4W F
(DE535/V525)
R1005 1-249-429-11 CARBON 10K 5% 1/4W
(DE535/SE491/V525)
R1006 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE535/V525)
R1007 1-249-429-11 CARBON 10K 5% 1/4W
(DE535/SE491/V525)
R1008 1-249-429-11 CARBON 10K 5% 1/4W
(DE535/SE491/V525)
R1009 1-249-385-11 CARBON 2.2 5% 1/6W F
(DE535/V525)
R1010 1-249-385-11 CARBON 2.2 5% 1/6W F
(DE535/V525)
RR101 1-249-437-11 CARBON 47K 5% 1/4W
RR102 1-249-437-11 CARBON 47K 5% 1/4W
RR103 1-249-437-11 CARBON 47K 5% 1/4W
RR104 1-249-437-11 CARBON 47K 5% 1/4W
RR105 1-249-437-11 CARBON 47K 5% 1/4W
RR106 1-249-437-11 CARBON 47K 5% 1/4W
RR107 1-249-437-11 CARBON 47K 5% 1/4W
RR108 1-249-437-11 CARBON 47K 5% 1/4W
RR109 1-249-437-11 CARBON 47K 5% 1/4W
RR110 1-249-437-11 CARBON 47K 5% 1/4W
RR111 1-249-437-11 CARBON 47K 5% 1/4W
RR112 1-249-437-11 CARBON 47K 5% 1/4W
RR113 1-249-437-11 CARBON 47K 5% 1/4W
RR114 1-249-437-11 CARBON 47K 5% 1/4W
RR115 1-249-437-11 CARBON 47K 5% 1/4W
RR116 1-249-437-11 CARBON 47K 5% 1/4W
RR117 1-249-437-11 CARBON 47K 5% 1/4W
RR118 1-249-437-11 CARBON 47K 5% 1/4W
RR119 1-249-437-11 CARBON 47K 5% 1/4W
RR120 1-249-437-11 CARBON 47K 5% 1/4W
RR121 1-249-437-11 CARBON 47K 5% 1/4W
RR122 1-249-437-11 CARBON 47K 5% 1/4W
RR123 1-249-437-11 CARBON 47K 5% 1/4W
RR124 1-249-437-11 CARBON 47K 5% 1/4W
(EXCEPT DE535:MY,SP/V525)
RR125 1-249-437-11 CARBON 47K 5% 1/4W
(EXCEPT DE535:MY,SP/V525)
RR126 1-249-437-11 CARBON 47K 5% 1/4W
RR127 1-249-437-11 CARBON 47K 5% 1/4W
RR128 1-249-437-11 CARBON 47K 5% 1/4W
RR129 1-249-437-11 CARBON 47K 5% 1/4W
< SWITCH >
S142 1-762-196-21 SWITCH, TACT (EXCEPT DE435:US,CND)
S142 1-762-875-21 SWITCH, KEYBOARD (DE435:US,CND)
S148 1-762-196-21 SWITCH, TACT (EXCEPT DE435:US,CND)
S148 1-762-875-21 SWITCH, KEYBOARD (DE435:US,CND)
< VIBRATOR >
X101 1-760-489-11 VIBRATOR, CERAMIC (5MHz)
X1000 1-767-938-21 VIBRATOR, CERAMIC (7.28MHZ) (DE535/V525)
************************************************************
1-672-994-11 HEADPHONE BOARD
*****************
< EARTH >
* EB502 1-537-738-21 TERMINAL, EARTH
< JACK >
J501 1-750-731-11 JACK (LARGE TYPE) (HEADPHONE)(SE491)
J501 1-750-733-11 JACK (LARGE TYPE) (HEADPHONE)
(DE435/V424/DE535)
J501 1-750-735-11 JACK (LARGE TYPE) (HEADPHONE)(V525)
************************************************************
A-4419-079-A INPUT BOARD, COMPLETE
**********************
(DE535/SE491/V525)
A-4419-220-A INPUT BOARD, COMPLETE
**********************
(EXCEPT AEP,EE,CIS/DE535/SE491/V525)
A-4419-232-A INPUT BOARD, COMPLETE (AEP,EE,CIS)
**********************
< CAPACITOR >
C201 1-126-961-11 ELECT 2.2uF 20% 50V
(DE535/SE491/V525)
C202 1-162-282-31 CERAMIC 100PF 10% 50V
(DE535/SE491/V525)
C203 1-125-896-91 MYLAR 0.0091uF 5% 50V
(DE535/SE491/V525)
C204 1-136-159-00 FILM 0.033uF 5% 50V
(DE535/SE491/V525)
C205 1-104-666-11 ELECT 220uF 20% 10V
(DE535/SE491/V525)
C206 1-126-961-11 ELECT 2.2uF 20% 50V
(DE535/SE491/V525)
C207 1-164-159-11 CERAMIC 0.1uF 50V
(DE535/SE491/V525)
C208 1-162-294-31 CERAMIC 0.001uF 10% 50V
(DE535/SE491/V525)
C209 1-126-965-11 ELECT 22uF 20% 50V
C211 1-104-664-11 ELECT 47uF 20% 16V
C213 1-104-664-11 ELECT 47uF 20% 16V
C214 1-162-294-31 CERAMIC 0.001uF 10% 50V
C215 1-126-965-11 ELECT 22uF 20% 50V
C230 1-164-159-11 CERAMIC 0.1uF 50V
C231 1-164-159-11 CERAMIC 0.1uF 50V
DISPLAY HEADPHONE INPUT
