Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 55 —
< RESISTOR >
R618 1-249-435-11 CARBON 33K 5% 1/4W
(AEP,EE,CIS)
R618 1-249-437-11 CARBON 47K 5% 1/4W
(EXCEPT AEP,EE,CIS)
R629 1-249-432-11 CARBON 18K 5% 1/4W
(AEP,EE,CIS)
R629 1-247-866-11 CARBON 30K 5% 1/4W
(US,CND,E)
R629 1-249-433-11 CARBON 22K 5% 1/4W
(MY,SP,AUS,CH)
R630 1-249-421-11 CARBON 2.2K 5% 1/4W F
R631 1-249-433-11 CARBON 22K 5% 1/4W
! R634 1-249-389-11 CARBON 4.7 5% 1/4W F
R635 1-249-431-11 CARBON 15K 5% 1/4W
R636 1-249-433-11 CARBON 22K 5% 1/4W
R646 1-249-425-11 CARBON 4.7K 5% 1/4W F
R647 1-249-429-11 CARBON 10K 5% 1/4W
R648 1-249-404-00 CARBON 82 5% 1/4W F
R649 1-249-404-00 CARBON 82 5% 1/4W F
R668 1-249-420-11 CARBON 1.8K 5% 1/4W F
R696 1-249-425-11 CARBON 4.7K 5% 1/4W F
R697 1-249-429-11 CARBON 10K 5% 1/4W
! R698 1-249-410-11 CARBON 270 5% 1/4W F
! R699 1-249-410-11 CARBON 270 5% 1/4W F
R729 1-249-432-11 CARBON 18K 5% 1/4W
(AEP,EE,CIS)
R729 1-247-866-11 CARBON 30K 5% 1/4W
(US,CND,E)
R729 1-249-433-11 CARBON 22K 5% 1/4W
(MY,SP,AUS,CH)
R730 1-249-421-11 CARBON 2.2K 5% 1/4W F
R731 1-249-433-11 CARBON 22K 5% 1/4W
! R734 1-249-389-11 CARBON 4.7 5% 1/4W F
R735 1-249-431-11 CARBON 15K 5% 1/4W
R746 1-249-425-11 CARBON 4.7K 5% 1/4W F
R747 1-249-429-11 CARBON 10K 5% 1/4W
R748 1-249-404-00 CARBON 82 5% 1/4W F
R749 1-249-404-00 CARBON 82 5% 1/4W F
! R784 1-249-389-11 CARBON 4.7 5% 1/4W F
< RELAY >
RY601 1-515-920-11 RELAY (24V)
RY651 1-755-267-11 RELAY
RY701 1-515-920-11 RELAY (24V)
< TERMINAL >
TM701 1-537-510-11 TERMINAL BOARD (SPEAKER) (6P)
************************************************************
1-672-997-11 SPK SELECT BOARD
*****************
< CONNECTOR >
* CNS107 1-695-808-11 CONNECTOR, PC BOARD 8P
< DIODE >
D117 8-719-911-19 DIODE 1SS119
D118 8-719-911-19 DIODE 1SS119
< SWITCH >
S101 1-762-196-21 SWITCH, TACT (1/u)
SW101 1-762-268-11 SWITCH, ROTARY (SPEAKERS)
************************************************************
1-672-995-11 STANDBY BOARD
**************
< CAPACITOR >
C901 1-161-494-00 CERAMIC 0.022uF 25V
C902 1-161-494-00 CERAMIC 0.022uF 25V
C903 1-126-767-11 ELECT 1000uF 20% 16V
C904 1-126-960-11 ELECT 1uF 20% 50V
C905 1-126-964-11 ELECT 10uF 20% 50V
C906 1-124-464-11 ELECT 0.22uF 20% 50V
C907 1-161-494-00 CERAMIC 0.022uF 25V
C908 1-164-159-11 CERAMIC 0.1uF 50V
C914 1-164-159-11 CERAMIC 0.1uF 50V
C917 1-164-159-11 CERAMIC 0.1uF 50V
< JACK >
CNJ901 1-785-834-11 OUTLET (1P) (DE435:US,CND/V424)
CNJ901 1-785-285-11 OUTLET, AC (1P) (AEP,E,EE,CIS,MY,SP)
CNJ901 1-251-417-11 OUTLET, A.C. (AUS)
CNJ901 1-251-718-11 OUTLET (2 GANG), AC
(DE535:US,CND,E/SE491/V525)
< CONNECTOR >
CNP901 1-564-321-00 PIN, CONNECTOR 2P
* CNP902 1-565-792-11 PIN, CONNECTOR 2P
* CNP903 1-573-565-11 PIN, CONNECTOR 5P (DE535:E)
< DIODE >
D901 8-719-024-99 DIODE 11ES2-NTA2B
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-911-19 DIODE 1SS119
D906 8-719-911-19 DIODE 1SS119
D907 8-719-911-19 DIODE 1SS119
< EARTH >
* EB900 1-537-738-21 TERMINAL, EARTH (US,CND)
* EB901 1-537-738-21 TERMINAL, EARTH
< FUSE >
! F901 1-532-504-31 FUSE T4AL 250V (E,MY,SP,AUS,CH)
! F901 1-532-506-51 FUSE TL6.3A 250V (AEP,EE,CIS)
! F901 1-533-310-11 FUSE, GLASS TUBE (6.3A/125V) (US,CND)
! F903 1-532-464-31 FUSE T2.5AL 250V (AEP,EE,CIS,MY,SP,AUS,CH)
! F904 1-532-504-31 FUSE T4AL 250V (DE535:E)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
REAR SPK SPK SELECT STANDBY
To Next Page
