Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 56 —
< IC >
IC901 8-759-333-83 IC NJM2103D
<TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q902 8-729-026-68 TRANSISTOR 2SD2525 (TP)
< RESISTOR >
R901 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
R902 1-249-429-11 CARBON 10K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W F
R904 1-249-421-11 CARBON 2.2K 5% 1/4W F
R905 1-249-428-11 CARBON 8.2K 5% 1/4W F
R906 1-249-421-11 CARBON 2.2K 5% 1/4W F
R908 1-249-433-11 CARBON 22K 5% 1/4W
R909 1-249-437-11 CARBON 47K 5% 1/4W
R910 1-249-429-11 CARBON 10K 5% 1/4W
R912 1-247-843-11 CARBON 3.3K 5% 1/4W
< RELAY >
! RY901 1-755-298-11 RELAY (EXCEPT DE435:US,CND)
! RY901 1-515-999-11 RELAY, POWER (DE435:US,CND)
< TRANSFORMER >
! T902 1-433-687-11 TRANSFORMER, POWER (AEP,EE,CIS,AUS,E)
! T902 1-433-685-11 TRANSFORMER, POWER (MY,SP,CH)
! T902 1-433-686-11 TRANSFORMER, POWER (US,CND)
************************************************************
A-4419-083-A SURR BOARD, COMPLETE (DE535/V525)
*********************
A-4419-203-A SURR BOARD, COMPLETE (SE491)
*********************
A-4419-221-A SURR BOARD, COMPLETE
*********************
(EXCEPT AEP,EE,CIS/DE535/SE491/V525)
A-4419-234-A SURR BOARD, COMPLETE (AEP,EE,CIS)
*********************
< CAPACITOR >
C219 1-126-964-11 ELECT 10uF 20% 50V
C221 1-126-964-11 ELECT 10uF 20% 50V
C223 1-126-964-11 ELECT 10uF 20% 50V
C225 1-126-964-11 ELECT 10uF 20% 50V
C269 1-126-964-11 ELECT 10uF 20% 50V
C271 1-126-964-11 ELECT 10uF 20% 50V
C280 1-126-960-11 ELECT 1uF 20% 50V
(DE435/DE535/V424/V525)
C281 1-126-960-11 ELECT 1uF 20% 50V
(DE435/DE535/V424/V525)
C282 1-126-960-11 ELECT 1uF 20% 50V
(DE435/DE535/V424/V525)
C283 1-162-215-31 CERAMIC 47PF 5% 50V
(DE435/DE535/V424/V525)
C284 1-162-215-31 CERAMIC 47PF 5% 50V
(DE435/DE535/V424/V525)
C285 1-104-664-11 ELECT 47uF 20% 16V
(DE435/DE535/V424/V525)
C287 1-164-159-11 CERAMIC 0.1uF 50V
(DE435/DE535/V424/V525)
C289 1-164-159-11 CERAMIC 0.1uF 50V
(DE435/DE535/V424/V525)
C290 1-104-664-11 ELECT 47uF 20% 16V
(DE435/DE535/V424/V525)
C291 1-126-960-11 ELECT 1uF 20% 50V
(DE435/DE535/V424/V525)
C301 1-124-250-11 ELECT 0.15uF 20% 50V
C302 1-126-962-11 ELECT 3.3uF 20% 50V
C303 1-124-250-11 ELECT 0.15uF 20% 50V
C304 1-126-963-11 ELECT 4.7uF 20% 50V
C305 1-126-959-11 ELECT 0.47uF 20% 50V
C306 1-126-963-11 ELECT 4.7uF 20% 50V
C307 1-126-959-11 ELECT 0.47uF 20% 50V
C308 1-136-165-00 FILM 0.1uF 5% 50V
C309 1-136-165-00 FILM 0.1uF 5% 50V
C310 1-136-177-00 FILM 1uF 5% 50V
C311 1-126-963-11 ELECT 4.7uF 20% 50V
C312 1-126-963-11 ELECT 4.7uF 20% 50V
C313 1-126-925-11 ELECT 470uF 20% 10V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-964-11 ELECT 10uF 20% 50V
C316 1-126-964-11 ELECT 10uF 20% 50V
C317 1-126-964-11 ELECT 10uF 20% 50V
C318 1-126-925-11 ELECT 470uF 20% 10V
C319 1-136-161-00 FILM 0.047uF 5% 50V
C320 1-136-157-00 FILM 0.022uF 5% 50V
C321 1-130-469-00 MYLAR 680PF 5% 50V
C322 1-126-959-11 ELECT 0.47uF 20% 50V
C323 1-164-159-11 CERAMIC 0.1uF 50V
C324 1-126-925-11 ELECT 470uF 20% 10V
C325 1-126-964-11 ELECT 10uF 20% 50V
C326 1-136-177-00 FILM 1uF 5% 50V
C327 1-136-165-00 FILM 0.1uF 5% 50V
C328 1-136-165-00 FILM 0.1uF 5% 50V
C329 1-126-959-11 ELECT 0.47uF 20% 50V
C330 1-126-963-11 ELECT 4.7uF 20% 50V
C331 1-126-959-11 ELECT 0.47uF 20% 50V
C332 1-126-963-11 ELECT 4.7uF 20% 50V
C333 1-124-250-11 ELECT 0.15uF 20% 50V
C334 1-126-962-11 ELECT 3.3uF 20% 50V
C335 1-124-250-11 ELECT 0.15uF 20% 50V
C337 1-136-165-00 FILM 0.1uF 5% 50V
C338 1-136-177-00 FILM 1uF 5% 50V
C339 1-126-959-11 ELECT 0.47uF 20% 50V
C340 1-126-925-11 ELECT 470uF 20% 10V
C341 1-164-159-11 CERAMIC 0.1uF 50V
C342 1-136-165-00 FILM 0.1uF 5% 50V
C343 1-137-358-11 FILM 0.0001uF 5% 50V
C344 1-126-934-11 ELECT 220uF 20% 10V
C345 1-126-964-11 ELECT 10uF 20% 50V
SURR
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
