Sony STR-DE497P - Digital Board Disassembly; Standby Board Disassembly

12
STR-DE497P/K4800P/K5800P
2-4. DIGITAL BOARD
4 CNS1
5 CNS2
1 CNP6
2 CNP5
8 bracket (digital
)
6 DIGITAL board
3 screw
(BVTP3 x 8)
7 screw
(BVTP3 x 8)
7 STANDBY board
1 CNP915
4 CNP804
5 CNP903
2 CNP802
3 CNP902
6 three screws
(BVTP3 x 8)
2-5. STANDBY BOARD
