49
STR-DE497P/K4800P/K5800P
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R615 1-249-405-11 CARBON 100 5% 1/4W F
R616 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R617 1-249-393-11 CARBON 10 5% 1/4W F
R618 1-249-389-11 CARBON 4.7 5% 1/4W F
R620 1-247-847-11 CARBON 4.7K 5% 1/4W
R621 1-247-850-11 CARBON 6.2K 5% 1/4W
R622 1-249-419-11 CARBON 1.5K 5% 1/4W
R623 1-247-871-11 CARBON 47K 5% 1/4W
R624 1-249-431-11 CARBON 15K 5% 1/4W
R625 1-249-439-11 CARBON 68K 5% 1/4W
R631 1-247-847-11 CARBON 4.7K 5% 1/4W
R634 1-249-404-00 CARBON 82 5% 1/4W F
R638 1-249-439-11 CARBON 68K 5% 1/4W
R640 1-247-863-11 CARBON 22K 5% 1/4W
R643 1-247-863-11 CARBON 22K 5% 1/4W
R648 1-247-843-11 CARBON 3.3K 5% 1/4W
R651 1-247-831-11 CARBON 1K 5% 1/4W
R652 1-249-439-11 CARBON 68K 5% 1/4W
R653 1-249-421-11 CARBON 2.2K 5% 1/4W
R654 1-249-439-11 CARBON 68K 5% 1/4W
R655 1-247-863-11 CARBON 22K 5% 1/4W
R656 1-247-863-11 CARBON 22K 5% 1/4W
R657 1-249-431-11 CARBON 15K 5% 1/4W
R660 1-249-421-11 CARBON 2.2K 5% 1/4W
R661 1-249-440-11 CARBON 82K 5% 1/4W
R663 1-249-414-11 CARBON 560 5% 1/4W
R664 1-249-405-11 CARBON 100 5% 1/4W F
R665 1-249-405-11 CARBON 100 5% 1/4W F
R666 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R667 1-249-393-11 CARBON 10 5% 1/4W F
R668 1-249-389-11 CARBON 4.7 5% 1/4W F
R669 1-247-847-11 CARBON 4.7K 5% 1/4W
R671 1-247-850-11 CARBON 6.2K 5% 1/4W
R672 1-249-419-11 CARBON 1.5K 5% 1/4W
R673 1-247-871-11 CARBON 47K 5% 1/4W
R674 1-249-431-11 CARBON 15K 5% 1/4W
R675 1-247-863-11 CARBON 22K 5% 1/4W
R676 1-247-863-11 CARBON 22K 5% 1/4W
R677 1-249-431-11 CARBON 15K 5% 1/4W
R680 1-247-863-11 CARBON 22K 5% 1/4W
R681 1-247-843-11 CARBON 3.3K 5% 1/4W
R690 1-247-887-00 CARBON 220K 5% 1/4W
0 R691 1-216-452-11 METAL OXIDE 180 5% 2W F
0 R692 1-215-888-00 METAL OXIDE 220 5% 2W F
(DE497P)
0 R692 1-215-889-00 METAL OXIDE 330 5% 2W F
(K4800P/K5800P)
R693 1-249-429-11 CARBON 10K 5% 1/4W
R694 1-249-429-11 CARBON 10K 5% 1/4W
R695 1-249-429-11 CARBON 10K 5% 1/4W
R696 1-249-435-11 CARBON 33K 5% 1/4W
R698 1-247-871-11 CARBON 47K 5% 1/4W
R699 1-247-895-00 CARBON 470K 5% 1/4W
R701 1-247-831-11 CARBON 1K 5% 1/4W
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-249-421-11 CARBON 2.2K 5% 1/4W
R704 1-249-439-11 CARBON 68K 5% 1/4W
R710 1-249-421-11 CARBON 2.2K 5% 1/4W
R711 1-249-440-11 CARBON 82K 5% 1/4W
R713 1-249-414-11 CARBON 560 5% 1/4W
R714 1-249-405-11 CARBON 100 5% 1/4W F
R715 1-249-405-11 CARBON 100 5% 1/4W F
R716 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R717 1-249-393-11 CARBON 10 5% 1/4W F
R718 1-249-389-11 CARBON 4.7 5% 1/4W F
R719 1-247-847-11 CARBON 4.7K 5% 1/4W
R721 1-247-850-11 CARBON 6.2K 5% 1/4W
R722 1-249-419-11 CARBON 1.5K 5% 1/4W
R723 1-247-871-11 CARBON 47K 5% 1/4W
R724 1-249-431-11 CARBON 15K 5% 1/4W
R725 1-249-439-11 CARBON 68K 5% 1/4W
R731 1-247-847-11 CARBON 4.7K 5% 1/4W
R732 1-249-381-11 CARBON 1 5% 1/4W F
R733 1-249-381-11 CARBON 1 5% 1/4W F
R734 1-249-404-00 CARBON 82 5% 1/4W F
R735 1-249-427-11 CARBON 6.8K 5% 1/4W
R736 1-247-831-11 CARBON 1K 5% 1/4W
R737 1-249-436-11 CARBON 39K 5% 1/4W
R740 1-247-863-11 CARBON 22K 5% 1/4W
R744 1-247-863-11 CARBON 22K 5% 1/4W
R745 1-247-863-11 CARBON 22K 5% 1/4W
R746 1-247-863-11 CARBON 22K 5% 1/4W
R747 1-249-431-11 CARBON 15K 5% 1/4W
R748 1-247-843-11 CARBON 3.3K 5% 1/4W
R750 1-247-863-11 CARBON 22K 5% 1/4W
R751 1-247-831-11 CARBON 1K 5% 1/4W
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-421-11 CARBON 2.2K 5% 1/4W
R754 1-249-439-11 CARBON 68K 5% 1/4W
R755 1-247-863-11 CARBON 22K 5% 1/4W
R756 1-247-863-11 CARBON 22K 5% 1/4W
R757 1-249-431-11 CARBON 15K 5% 1/4W
R758 1-247-843-11 CARBON 3.3K 5% 1/4W
R760 1-249-421-11 CARBON 2.2K 5% 1/4W
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W
R764 1-249-405-11 CARBON 100 5% 1/4W F
R765 1-249-405-11 CARBON 100 5% 1/4W F
R766 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R767 1-249-393-11 CARBON 10 5% 1/4W F
R768 1-249-389-11 CARBON 4.7 5% 1/4W F
R769 1-247-847-11 CARBON 4.7K 5% 1/4W
R770 1-247-871-11 CARBON 47K 5% 1/4W
R771 1-247-850-11 CARBON 6.2K 5% 1/4W
R772 1-249-419-11 CARBON 1.5K 5% 1/4W
R773 1-247-871-11 CARBON 47K 5% 1/4W
R775 1-249-439-11 CARBON 68K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
R780 1-249-429-11 CARBON 10K 5% 1/4W
R791 1-247-847-11 CARBON 4.7K 5% 1/4W
0 R792 1-215-868-00 METAL OXIDE 680 5% 1W F
R793 1-249-404-00 CARBON 82 5% 1/4W F
0 R794 1-215-868-00 METAL OXIDE 680 5% 1W F
R802 1-249-409-11 CARBON 220 5% 1/4W F
R803 1-249-389-11 CARBON 4.7 5% 1/4W F
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
