STR-DE497P/K4800P/K5800P
5
MAIN board
1
two screws
(+BV SUMITITE (B3))
2
two screws
(+BV SUMITITE (B3))
4
two screws
(+BV SUMITITE (B3)
)
3
screw
(+BV SUMITITE (B3))
2-6. MAIN BOARD
